Airtac F-PB-CJ Rear Swing Bracket Assembly Kit F-PB16CJ
AirTAC F-PB-CJ Rear Swing Bracket Kit F-PB16CJ Specifications
- Model: F-PB16CJ
- Type: Rear swing bracket complete kit (pre-assembled)
- Compatible cylinder bore: Φ16mm
- Material: Aluminum alloy (ALDC12) with black anodized finish
- Mounting hole spacing: 30±0.2mm horizontal × 18±0.15mm vertical
- Swing angle: ±5° adjustable
- Fastener grade: Class 8.8 steel bolts (M6×12mm)
- Load capacity: Max 45N·m torque resistance
- Surface hardness: HV 120-150
- Weight: 280g ±5%
- Dimensions: 72mm(L) × 42mm(W) × 34mm(H)
- Operating temperature: -20℃ to 80℃
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered swing bracket with anti-loosening threadlock treatment, designed for angular compensation in compact pneumatic systems. Features dual-bearing pivot structure for smooth rotation and integrated shim plates for gap adjustment. Compatible with ISO 15552 cylinder profiles.
- 90° swing mechanisms in pick-and-place robots
- Vibration damping for sensor mounting platforms
- Adjustable actuator supports in conveyor diverters
- Precision alignment in semiconductor handling arms
- Modular fixture systems for automotive assembly
Installation protocol:
Apply 0.3-0.5Nm torque during bolt tightening. Lubricate pivot points with ISO VG32-grade
grease monthly in high-cycle applications (>5,000 operations/day). Avoid using impact tools.
| Property | Property Value |
|---|---|
| sku | F-PB16CJ |
