Airtac F-PB-FA Front Flange Mounting Plate Assembled Kit F-PB6FA
$3.48
Regular price
$10.98
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-PB6FA
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Cylinder Accessories
Brand: Airtac
Series: F-PB-FA Front Flange Mounting Bracket Complete Set
Engineered for precision alignment in pneumatic cylinder installations
Pre-assembled front flange configuration ensures stable mounting interface
CNC-machined bracket with standardized hole patterns for ISO cylinder compatibility
Includes mounting hardware and anti-vibration shim components
Surface-treated with anti-corrosion coating for industrial environments
Dual-bearing support design minimizes lateral load on cylinder rod
Installation note:
Apply 20-30N·m torque during fastening. Use thread locker on screws for
vibration-prone environments. Align mating surfaces within 0.1mm tolerance
to prevent lateral stress.
Brand: Airtac
Series: F-PB-FA Front Flange Mounting Bracket Complete Set
AirTAC F-PB-FA Series Front Flange Mounting Plate Kit F-PB6FA
- Model: F-PB6FA (Complete Kit)
- Type: Front flange mounting bracket assembly
- Material: Aluminum alloy ADC12
- Mounting hole spacing: 40mm × 40mm square pattern
- Bolt specification: M6 × 1.0 thread pitch
- Surface treatment: Black anodized
- Temperature resistance: -20°C to 120°C
- Max load capacity: 500N static load
- Weight: 0.45kg ±2%
- Dimensions: 60mm(L) × 30mm(W) × 15mm(H)
- Included components: Mounting plate, 4×M6×20 hex socket screws, 4×M6 flange nuts, 4×DIN125 flat washers
Precision-machined mounting solution for cylinder installation, featuring anti-corrosion coating and CNC-drilled alignment holes. The chamfered edges prevent thread damage during assembly. Compatible with ISO15552 standard cylinders and most 40mm bore pneumatic actuators.
Typical Applications:
- Linear actuator mounting in robotic arm joints
- Pneumatic clamping systems in CNC machinery
- Assembly line positioning mechanisms
- Packaging equipment vertical lift systems
- Automated door cylinder installations
Installation note:
Apply 20-30N·m torque during fastening. Use thread locker on screws for
vibration-prone environments. Align mating surfaces within 0.1mm tolerance
to prevent lateral stress.
| Property | Property Value |
|---|---|
| sku | F-PB6FA |
