Airtac F-PB-LB Axial Fixing Bracket Assembly Kit F-PB12LB
$5.54
Regular price
$13.04
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-PB12LB
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Cylinder Accessories
Brand: AirTAC
Series: F-PB-LB Axial Mounting Bracket Kit
Product Description:
The F-PB-LB Axial Mounting Bracket Kit by AirTAC is a high-precision engineered solution for cylinder alignment and positional stability. Designed with durable anodized aluminum construction, this assembly ensures secure axial fixation and vibration resistance in pneumatic systems. The kit includes pre-configured mounting hardware optimized for quick installation, maintaining perpendicularity tolerance of ≤0.1mm for critical industrial automation applications. Its modular design supports smooth integration with ISO standard cylinder profiles, featuring thermal-treated steel fasteners and anti-corrosion surface treatment for extended service life in harsh environments.
Mounting protocol:
Apply 0.3-0.5Nm torque using JIS B 1082 compliant tools.
Requires rail end machining with Ra 3.2μm or better finish.
Perform concentricity check after 24hrs of installation.
AirTAC F-PB-LB Axial Fixing Bracket Kit F-PB12LB Technical Details
- Full model designation: F-PB12LB
- Product category: Pre-assembled linear guide axial restraint kit
- Material: 6063-T5 aluminum alloy (anodized surface)
- Compatible rail width: 12mm (optimized for HGH12/HGW12 series)
- Mounting hole pattern: 32mm × 15mm rectangular array
- Fastener specifications: M4×8mm stainless steel cap screws (4 pcs included)
- Clamping force capacity: 1,200N axial load (static)
- Surface hardness: HV 450-500
- Weight: 84g ±2g (including hardware)
- Dimensions: 42mm(L) × 24mm(W) × 16mm(H)
- Operating temperature: -20℃ to 120℃ (dry environment)
- Corrosion resistance: 96hr salt spray test passed
Precision-machined anti-creep solution for linear motion systems, featuring dual-contact surfaces and vibration-damped design. The kit includes pre-installed thread-locking compound on fasteners for permanent installations. Compatible with ISO 10285 standard linear guides.
Implementation Scenarios:
- CNC router Z-axis end stop reinforcement
- Automated warehouse shuttle positioning
- 3D printer gantry alignment systems
- Semiconductor wafer handling robots
- Laser cutting machine rail protection
Mounting protocol:
Apply 0.3-0.5Nm torque using JIS B 1082 compliant tools.
Requires rail end machining with Ra 3.2μm or better finish.
Perform concentricity check after 24hrs of installation.
| Property | Property Value |
|---|---|
| sku | F-PB12LB |
