Airtac F-RMSF Axial Fixing Bracket Assembly Kit F-RMSF16LB
AirTAC F-RMSF16LB Axial Fixing Bracket Kit Technical Details
- Model: F-RMSF16LB (Complete Assembly Kit)
- Material: Aluminum alloy 6063-T5 with hard anodized finish
- Axial load capacity: 2,500 N (static), 1,200 N (dynamic)
- Mounting type: Dual V-groove rail clamping
- Compatible rail width: 16mm (SBR16/SHS16 series)
- Clamping force: 30-35 N·m torque recommended
- Surface hardness: HV 400±20
- Weight: 184g ±2% (including fasteners)
- Dimensions: 62mm(L) × 38mm(W) × 28mm(H)
- Operating temperature: -40℃ to 120℃
- Corrosion resistance: 500hr salt spray test passed
- Vibration resistance: 5-2000Hz, 20G acceleration
- Repeat positioning accuracy: ±0.02mm
- IP rating: IP67 when installed with compatible seals
Precision-engineered axial retention solution for linear motion systems, featuring anti-backlash wedge clamping mechanism with integrated dust-resistant seals. The zinc-nickel plated M6×12 mounting screws (ISO 7380-1) include thread-locking compound for vibration resistance. Requires matched installation with SBR/SHS16 rails using torque wrench.
- High-speed CNC router Z-axis stabilization
- Semiconductor wafer handling robots
- Automated optical inspection equipment
- Lithium battery cell stacking machines
- Pharmaceutical blister packaging lines
Installation protocol:
Clean rail surfaces with isopropyl alcohol before mounting.
Apply incremental torque (10N·m → 20N·m → 30N·m) in diagonal sequence.
Verify parallelism with 0.05mm/m tolerance using dial indicator.
| Property | Property Value |
|---|---|
| sku | F-RMSF16LB |
| Bore Diameter | 16mm |
