Airtac F-SI-CA Single Lug Bracket Assembly Kit F-SI200CA
$120.94
Regular price
$128.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-SI200CA
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Cylinder Accessories
Brand: AirTAC
Series: F-SI-CA
**Single Lug Mounting Bracket Complete Assembly Kit**
Engineered for robust cylinder stabilization in pneumatic systems, this precision-machined aluminum alloy bracket features an anodized surface treatment for enhanced corrosion resistance. The single-lug design ensures rigid connections while maintaining angular adjustability for versatile installation compatibility.
**Key Specifications**
• Material: Aluminum Alloy (6063-T5)
• Surface Treatment: Anodized
• Mounting Style: Single Ear (Lateral Fixation)
• Load Capacity: Optimized for ISO/VDMA standard cylinder series
• Pre-assembled configuration with standard fasteners included
**Application**
Ideal for linear actuator installations requiring vibration-damped fixation in automation equipment, packaging machinery, and industrial robotics. The complete kit enables rapid deployment with ±2° axial compensation tolerance, ensuring parallel alignment for cylinder rod extensions.
**Compliance**
Manufactured under ISO 9001:2015 quality standards. Compatible with AirTAC SC/SU/SI series cylinders and industrial pneumatic equipment.
*Note: Includes M6 Class 8.8 mounting hardware and anti-loosening washers. Torque specifications: 12-14 N·m.*
Installation protocol:
Use spring washers (included) for all M6 fasteners. Lubricate guide rails with ISO VG32 hydraulic oil before sliding cylinder into position. Maximum permissible side load: 10% of static capacity.
AirTAC F-SI-CA Single-Ear Mounting Bracket Kit F-SI200CA Technical Details
- Model: F-SI200CA
- Type: Standard single-ear bracket kit (pre-assembled)
- Material: Aluminum alloy ADC12
- Surface treatment: Anodized (silver)
- Weight: 850g ±2%
- Dimensions: 200mm(L) × 50mm(W) × 30mm(H)
- Mounting hole specifications: 4×M6 threaded holes (depth 12mm)
- Hole spacing: 180mm center-to-center (longitudinal)
- Load capacity: 25kg dynamic / 80kg static
- Temperature resistance: -20℃ to 120℃
- Vibration resistance: ≤50m/s² (10-150Hz)
- Compatible cylinder series: SC/SU/SI 32-100mm bore sizes
- Corrosion protection: MIL-STD-810F salt spray tested 96hrs
- Installation torque: 12-15N·m (M6 bolts)
- IP rating: IP54 (as installed)
Heavy-duty mounting solution with integrated vibration damping, featuring precision-machined alignment grooves for rapid cylinder installation. The asymmetric ear design allows offset load distribution and tool-free angle adjustment (±15°). Includes pre-installed wear-resistant brass bushings and stainless steel fasteners.
Typical Applications:
- Pneumatic cylinder mounting in automated assembly lines
- Sensor bracket for robotic welding stations
- Support structure for conveyor belt tensioning systems
- Base platform for custom pneumatic gripper configurations
- Vibration-sensitive metrology equipment mounting
Installation protocol:
Use spring washers (included) for all M6 fasteners. Lubricate guide rails with ISO VG32 hydraulic oil before sliding cylinder into position. Maximum permissible side load: 10% of static capacity.
