Airtac F-SI-CA Single Lug Bracket Assembly Kit F-SI40CA
AirTAC F-SI-CA Single Ear Fixing Bracket Kit F-SI40CA Technical Details
- Model: F-SI40CA (Complete Kit)
- Material: High-grade aluminum alloy ADC12
- Surface treatment: Black anodized oxidation
- Compatible cylinder series: SI series Ø40mm bore size
- Mounting hole spacing: 60±0.2mm (center-to-center)
- Bolt specifications: M8×1.25 mounting thread
- Lateral load capacity: 1,470N max (static condition)
- Weight: 380g ±5% (including all mounting hardware)
- Dimensions: 85mm(L) × 42mm(W) × 28mm(H)
- Operating temperature: -20℃ to 120℃
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
- Corrosion resistance: 96hrs salt spray test compliant
- Included components: Bracket body, M8 hex nuts (2pcs), flat washers (2pcs), spring washers (2pcs)
Heavy-duty single ear mounting bracket engineered for precise alignment and vibration damping in pneumatic cylinder installations. Features CNC-machined contact surfaces with ±0.1mm parallelism tolerance, ensuring minimal axial play. The offset ear design allows 180° mounting flexibility while maintaining 4.8-grade anti-loosening performance under continuous vibration.
- Fixed mounting of ISO 15552 standard cylinders in automated assembly lines
- Robotic welding fixture stabilization
- Packaging machinery with high-cycle reciprocating motion
- Material handling systems requiring impact resistance
- Semiconductor equipment needing EMI-free mounting solution
Installation protocol:
Apply 25-35N·m torque using calibrated wrench during assembly.
Use shim washers if mounting surface flatness exceeds 0.2mm/mm².
Perform torque recheck after 50 operating cycles.
| Property | Property Value |
|---|---|
| sku | F-SI40CA |
