Airtac F-SI-CB Double Lug Bracket Assembly Kit F-SI125CB
AirTAC F-SI-CB Double Ear Bracket Kit F-SI125CB Technical Details
- Model: F-SI125CB (Complete Bracket Assembly)
- Type: Standardized cylinder mounting bracket kit
- Material: Aluminum alloy 6063-T5 with hard anodized finish
- Compatible Cylinder Series: SI series Ø125mm bore size
- Mounting Style: Dual ear fixed pivot mounting
- Bolt Specifications: M12×1.5 mounting bolts included
- Surface Treatment: Black anodizing (8-12μm thickness)
- Temperature Range: -20℃ to 80℃ (continuous operation)
- Dynamic Load Capacity: 2,500N (axial), 1,800N (radial)
- Static Load Rating: 4,000N maximum
- Weight: 0.85kg (complete assembly)
- Dimensions: 150mm(L) × 80mm(W) × 25mm(H)
- Hardware Included: Class 8.8 steel bolts, flat washers, lock nuts
- Surface Roughness: Ra ≤3.2μm on contact surfaces
- Corrosion Resistance: 96hr salt spray test passed
Robust dual-ear mounting solution designed for heavy-duty pneumatic cylinder installations. Features precision-machined alignment surfaces and vibration-damping design, with integrated shim adjustment capability (±0.5mm). The pre-assembled kit includes all necessary ISO-certified fasteners for immediate installation.
- Industrial automation press machinery
- Material handling systems with high moment loads
- Packaging equipment with reciprocating actuators
- Automotive assembly line positioning units
- Die-casting machine cylinder supports
Installation Guidelines:
Apply 20-25N·m torque to M12 bolts using cross-tightening sequence.
Use Loctite 243 thread locker for high-vibration environments.
Maintain 0.1-0.3mm clearance between bracket and cylinder flange during assembly.
