Airtac F-SI-LB Axial Fixing Bracket Assembly Kit F-SI63LB
Category: Cylinder Accessories | Brand: Airtac | Series: F-SI-LB
The Airtac F-SI-LB Axial Mounting Bracket Complete Kit is a precision-engineered cylinder accessory designed for rigid axial fixation of pneumatic cylinders in industrial automation systems. Featuring high-strength anodized aluminum alloy construction, this assembly ensures vibration resistance and corrosion protection in demanding environments. The kit includes pre-assembled components with standardized mounting interfaces, enabling seamless integration with F-SI series cylinders while maintaining strict coaxial alignment. Its compact design optimizes spatial efficiency in confined machinery layouts, and the modular structure simplifies maintenance operations. The product complies with ISO 6432 mounting specifications, making it ideal for applications requiring precise linear motion control in robotics, material handling, and automated production lines.
AirTAC F-SI-LB Series Axial Fixing Bracket Kit F-SI63LB Specifications
- Model: F-SI63LB
- Type: Linear guide axial fixation kit
- Material: Aluminum alloy (AL6063-T5) with black anodized finish
- Compatible rail size: 63 series linear guides
- Mounting pattern: Dual M8×1.25 threaded holes (depth 15mm)
- Clamping force: 1,500N axial load capacity
- Surface hardness: HV 80-100
- Temperature range: -20℃ to 100℃ (continuous operation)
- Corrosion resistance: 96hr salt spray test compliant
- Weight: 0.82kg ±3%
- Dimensions: 125mm(L) × 63mm(W) × 42mm(H)
- Fastener torque: 18-22N·m (M8 bolts)
- Parallelism tolerance: ≤0.02mm/m
- Surface roughness: Ra 1.6μm (contact surfaces)
Precision-machined axial restraint system designed for high-rigidity linear motion applications. Features dual preload adjustment screws (M5×0.8) for fine-tuning alignment compensation. Includes vibration-damping rubber pads (Shore A 70±5) and stainless steel mounting hardware (A2-70 grade).
- CNC machine tool slide unit end stops
- Automated warehouse shuttle positioning
- 3D printer gantry axis stabilization
- Semiconductor wafer handling robots
- Laser cutting machine rail systems
Installation protocol:
Apply 5-10μm thick lithium-based grease to contact surfaces before assembly.
Use dial indicator to verify ≤0.05mm axial runout during final tightening sequence.
Replace anti-creep washers every 5,000 operational hours.
| Property | Property Value |
|---|---|
| sku | F-SI63LB |
