Airtac F-SI-TCM Trunnion Mount Complete Assembly Kit F-SI160TCM1
AirTAC F-SI-TCM Trunnion Mount Bracket Kit F-SI160TCM1 Specifications
- Model: F-SI160TCM1
- Type: Complete trunnion mount bracket kit with integrated hardware
- Compatible Series: Designed for SI-16 series cylinders
- Material: Aluminum alloy (AL6063-T5)
- Surface Treatment: Hard anodized (black)
- Mounting Hole Pattern: 32mm × 32mm square configuration
- Load Capacity: Dynamic 40kg / Static 120kg
- Angle Adjustment: ±3° fine tuning capability
- Mounting Screws: M8×20mm stainless steel (4 pcs included)
- Temperature Range: -20℃ to 120℃
- Vibration Resistance: ≤20 m/s² (ISO 10816-3)
- Weight: 580g ±2%
- Dimensions: 160mm(L) × 45mm(W) × 62mm(H)
Precision-engineered mounting solution for cylinder stabilization, featuring anti-corrosion treatment and multi-axis adjustability. The hardened pivot mechanism enables smooth angular compensation during mechanical motion cycles. Includes pre-loaded thrust bearings for reduced rotational friction (0.08-0.12μ).
- Robotic welding arm articulation points
- High-cycle packaging machine pusher mechanisms
- Automated conveyor sorting systems
- CNC tool changer positioning units
- Semiconductor handling robot joints
Installation protocol:
Apply 20-25N·m torque to M8 fasteners using cross-tightening sequence.
Lubricate pivot shaft with ISO VG32 hydraulic oil before initial operation.
Max lateral offset tolerance: 0.2mm.
| Property | Property Value |
|---|---|
| sku | F-SI160TCM1 |
