Airtac JSI Series Standard Cylinder JSI100X100
2. Features profiled bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. JSI Series utilizes cross-braced aluminum alloy tubing with tie-rod-free design, offering superior corrosion resistance;
4. Reduced overall length compared to ISO15552 standard cylinders of equivalent bore size;
5. Precision-adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive selection of bore sizes and mounting accessories available for customized system integration.
Category: Standard Cylinders, Brand: AirTAC, Series: JSI
AirTAC JSI100X100 Standard Cylinder Specifications
- Model: JSI100X100
- Bore size: 100mm
- Stroke: 100mm
- Action type: Double-acting
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Adjustable air cushion (both ends)
- Port size: Rc1/2 (G1/2 optional)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Piston rod material: Chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy
- Mounting types: Basic type (MF1), front flange (MF2), rear flange (MF3), foot mounting (MF4)
- Protection rating: IP54 (standard), IP67 (optional wiper upgrade)
- Weight: 6.8 kg (dry, without accessories)
- Dimensions:
- Total length: 328mm (minimum retracted length)
- Body diameter: 125mm
- Mounting hole spacing: 160mm (front flange pattern)
- Rod end thread: M20×1.5
High-torque industrial cylinder designed for heavy-duty applications requiring precise linear motion. Features enhanced side load capacity through integrated guide bushings and multi-layered sealing system. Optional magnetic piston version (JSI100X100-M) enables position sensing. Requires 5μm filtered air with ISO 8573-1:2010 Class 3 air quality.
- Automotive welding fixture clamping
- Steel mill conveyor gate actuation
- Injection molding machine ejector systems
- Paper processing equipment tension control
- Heavy material handling in warehouse automation
Installation note:
For vertical mounting, use auxiliary rod support when stroke exceeds 500mm.
Lubricate rod weekly with ISO VG32 hydraulic oil in high-cycle applications (>500,000 cycles/year).
| Property | Property Value |
|---|---|
| sku | JSI100X100 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 100mm |
