Airtac JSI Series Standard Cylinder JSI100X100S
2. Features profiled bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. JSI Series utilizes cross-braced aluminum alloy tubing with tie-rod-free design, offering superior corrosion resistance;
4. Reduced overall length compared to ISO15552 standard cylinders of equivalent bore size;
5. Precision-adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive selection of bore sizes and mounting accessories available for customized system integration.
Category: Standard Cylinders, Brand: AirTAC, Series: JSI
AirTAC JSI Standard Cylinder JSI100X100S Technical Specifications
- Model: JSI100X100S
- Bore size: 100mm
- Stroke: 100mm (customizable 25-500mm)
- Operating pressure: 0.05-1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable air cushion (both ends)
- Piston speed: 50-750 mm/s
- Port size: Rc1/4 (G1/4 optional)
- Mounting type: Basic foot mounting (MF1)
- Rod end type: Female thread (M20×1.5)
- Piston rod material: Chrome-plated carbon steel
- Tube material: Aluminum alloy 6063-T5
- Seal material: NBR + PU combination
- Weight: 4.8 kg (excluding accessories)
- Dimensions (L×W×H):
- Basic length: 265mm (minimum retracted length)
- Stroke-adjusted length: 265mm + stroke
- Body width: 112mm (mounting surface)
- Height with rod: 138mm (rod extended)
High-torque industrial cylinder designed for heavy-load applications requiring precise linear motion. Features double-acting operation with corrosion-resistant construction and magnetic piston for position sensing compatibility. Optimal for applications demanding ≥10,000km service life under ISO 6432 standards.
- Press machine tooling systems
- Automotive assembly line clamping
- Foundry equipment actuation
- Palletizing robot end-effectors
- Injection molding machine ejectors
Installation protocol:
Lubricate with ISO VG32 hydraulic oil before initial operation.
Maintain 0.3mm minimum lateral clearance during alignment.
Requires 5μm filtered air supply with automatic drain.
| Property | Property Value |
|---|---|
| sku | JSI100X100S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 100mm |
