Airtac JSI Series Standard Cylinder JSI100X100STC
2. Features profiled bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. JSI Series utilizes cross-braced aluminum alloy tubing with tie-rod-free design, offering superior corrosion resistance;
4. Reduced overall length compared to ISO15552 standard cylinders of equivalent bore size;
5. Precision-adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive selection of bore sizes and mounting accessories available for customized system integration.
Category: Standard Cylinders, Brand: AirTAC, Series: JSI
AirTAC JSI100X100STC Standard Cylinder Specifications
- Model: JSI100X100STC
- Type: ISO 6432 standard cylinder (double-acting)
- Bore size: 100mm
- Stroke: 100mm (customizable 25-500mm)
- Operating pressure: 0.05-1.0 MPa
- Cushion type: Adjustable rubber buffer (STC suffix)
- Temperature range: -20℃ to 80℃
- Port size: G3/8 (NPT1/4 optional)
- Mounting type: Basic MF1 (various options available)
- Rod material: Chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU combination
- Protection rating: IP65 (standard), IP67 (optional)
- Weight: 3.8kg ±2% (with standard accessories)
- Dimensions: 345mm(L) × 110mm(W) × 110mm(H) (at 100mm stroke)
High-force industrial cylinder featuring precision honed tube and wear-resistant seals. The STC version incorporates dual adjustable cushions for smooth end-of-stroke deceleration. Designed for heavy-duty cycles with 5,000km minimum service life at rated load. Requires 40μm filtered air with lubrication (ISO VG32 recommended).
- Press machine clamping mechanisms
- Automotive welding fixture positioning
- Packaging line gate actuators
- Foundry equipment door operators
- Plastic injection molding ejectors
Installation tip:
Allow 15mm minimum clearance for cushion adjustment screws.
For vertical mounting, use rod-down orientation to prevent seal wear.
Lubricate through air port weekly in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | JSI100X100STC |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 100mm |
