Airtac JSI Series Standard Cylinder JSI100X100TC
2. Features profiled bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. JSI Series utilizes cross-braced aluminum alloy tubing with tie-rod-free design, offering superior corrosion resistance;
4. Reduced overall length compared to ISO15552 standard cylinders of equivalent bore size;
5. Precision-adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive selection of bore sizes and mounting accessories available for customized system integration.
Category: Standard Cylinders, Brand: AirTAC, Series: JSI
AirTAC JSI Standard Cylinder JSI100X100TC Technical Details
- Model: JSI100X100TC
- Bore size: 100mm
- Stroke: 100mm (customizable: 25-500mm)
- Operating pressure: 0.05-1.0 MPa
- Cushion type: Adjustable rubber buffer + air cushion
- Mounting style: Basic type (MF1) with front/rear threaded mounting
- Port size: G3/8 (NPT1/2 optional)
- Piston speed: 50-750 mm/s
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Body material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated carbon steel (JIS S45C)
- Weight: 3.8 kg (bare cylinder without accessories)
- Dimensions: 240mm(L) × 100mm(W) × 100mm(H) (at mid-stroke position)
- ISO standard: Compliant with ISO 6432
- Protection rating: IP54 (standard), IP67 available on request
High-torque industrial cylinder featuring dual cushioning system and corrosion-resistant construction. The JSI series utilizes a precision honed cylinder tube (Ra≤0.2μm) with wear-resistant seals, achieving over 5,000km service life under rated conditions. Includes magnetic piston for sensor compatibility and anti-rotation rod design.
- Automated assembly line clamping mechanisms
- Die-casting machine ejection systems
- Packaging equipment pressurization units
- Plastic injection molding machine actuators
- Heavy-duty material handling gates
Installation guidelines:
Maintain 0.5-1mm alignment tolerance during mounting. Lubricate with ISO VG32 hydraulic oil
if manual lubrication required. For vertical installations, use rod-down orientation
and add guide mechanisms when lateral forces exceed 10% of thrust rating.
| Property | Property Value |
|---|---|
| sku | JSI100X100TC |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 100mm |
