Airtac JSI Series Standard Cylinder JSI100X1200S
2. Features profiled bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. JSI Series utilizes cross-braced aluminum alloy tubing with tie-rod-free design, offering superior corrosion resistance;
4. Reduced overall length compared to ISO15552 standard cylinders of equivalent bore size;
5. Precision-adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive selection of bore sizes and mounting accessories available for customized system integration.
Category: Standard Cylinders, Brand: AirTAC, Series: JSI
AirTAC JSI Standard Cylinder JSI100X1200S Technical Specifications
- Model Code: JSI100X1200S
- Type: ISO 15552 compliant double-acting cylinder
- Bore size: Ø100 mm
- Stroke length: 1200 mm (±1.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa (1–9 bar)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Piston speed: 50–800 mm/s (lubricated)
- Ambient temperature: -20℃ to +80℃
- Port thread: G3/8 (NPT1/4 optional)
- Seal material: Nitrile rubber (NBR) standard (FKM available)
- Piston rod material: Chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy (6063-T5)
- Weight: 18.7 kg (without accessories)
- Dimensions (L×W×H):
- Extended length: 1445 mm
- Retracted length: 245 mm
- Mounting face width: 112 mm
- Height with standard mounts: 128 mm
- ISO mounting variants: VDMA/ISO 15552 front flange, rear foot, or axial mounts
- Position sensing: Pre-drilled slots for magnetic sensors (no built-in switch)
High-thrust industrial cylinder designed for heavy-duty linear motion applications requiring extended stroke precision. Features dual anti-rotation guide rods (optional) and corrosion-resistant construction. The 1.2m stroke version requires special alignment procedures during installation to prevent rod deflection. Requires ISO VG32 hydraulic oil lubrication for optimal seal performance.
- Automotive press line material handling systems
- Steel mill door actuators for furnace access
- Paper converting machinery web tension control
- Shipbuilding jig positioning systems
- Plastic injection molding machine ejectors
Installation criticals:
For strokes over 1000mm, mandatory use of intermediate rod support (AIRTAK SMC-F12 kit recommended).
Maintain 0.5mm/m alignment tolerance. Lubricate through air supply (oil mist type FRL required).
| Property | Property Value |
|---|---|
| sku | JSI100X1200S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 1200mm |
