Airtac JSI Series Standard Cylinder JSI100X125TC
2. Features profiled bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. JSI Series utilizes cross-braced aluminum alloy tubing with tie-rod-free design, offering superior corrosion resistance;
4. Reduced overall length compared to ISO15552 standard cylinders of equivalent bore size;
5. Precision-adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive selection of bore sizes and mounting accessories available for customized system integration.
Category: Standard Cylinders, Brand: AirTAC, Series: JSI
AirTAC JSI Series Standard Cylinder JSI100X125TC Technical Details
- Model Code: JSI100X125TC
- Bore Size: 100mm
- Stroke: 125mm
- Mounting Type: TC (Front Flange Mount)
- Operating Pressure: 0.1-1.0 MPa
- Cushioning: Adjustable Air Cushion (Both Ends)
- Temperature Range: -20℃ to 80℃
- Port Size: Rc1/4 (NPT1/4 Optional)
- Piston Rod Thread: M20×1.5
- Material:
- Cylinder Tube: Aluminum Alloy Hard Oxidation
- End Caps: Die-Cast Aluminum
- Piston Rod: Stainless Steel (SUS304)
- Seal Material: Nitrile Butadiene Rubber (NBR)
- Protection Class: IP65 (Dust & Water Jet Protected)
- Weight: 6.8kg ±2%
- Dimensions:
- Total Length (Extended): 365mm
- Body Diameter: 128mm
- Mounting Flange Width: 160mm
- Stroke Tolerance: +2.0mm
- Sensor Compatibility: Built-in slots for magnetic switches (M9/M12)
High-torque industrial cylinder designed for heavy-duty linear motion applications. Features triple sealing protection (rod wiper + primary seal + guide bearing) for extended service life. The hard-anodized inner bore reduces friction loss by 18% compared to standard cylinders. Includes anti-rotation mechanism for precise load guidance.
- Automated palletizing systems
- Injection molding machine ejectors
- Steel mill conveyor gate controls
- Paper processing equipment
- Automotive welding fixtures
Installation Guidelines:
Maintain 0.05-0.1mm alignment tolerance during mounting. Lubricate through air port with ISO VG32 hydraulic oil before initial operation. For vertical installations exceeding 45° angle, use additional rod-end support bracket (accessory code: BR-100TC).
| Property | Property Value |
|---|---|
| sku | JSI100X125TC |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 125mm |
