Airtac JSI Series Standard Cylinder JSI100X1400S
2. Features profiled bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. JSI Series utilizes cross-braced aluminum alloy tubing with tie-rod-free design, offering superior corrosion resistance;
4. Reduced overall length compared to ISO15552 standard cylinders of equivalent bore size;
5. Precision-adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive selection of bore sizes and mounting accessories available for customized system integration.
Category: Standard Cylinders, Brand: AirTAC, Series: JSI
AirTAC JSI Series Standard Cylinder JSI100X1400S Technical Details
- Model: JSI100X1400S
- Type: ISO 15552 compliant double-acting cylinder
- Bore size: Ø100 mm
- Stroke: 1400 mm (adjustable cushioning)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushions (both ends)
- Port size: G3/8 (standard) or optional NPT1/2
- Mounting style: Basic type (foot/rod flange optional)
- Piston rod material: Hard chrome-plated steel (Cr-Mo)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (standard) / PU (optional)
- Weight: 24.8 kg ±2% (without accessories)
- Dimensions: 1502mm(L) × 128mm(W) × 128mm(H)
- Protection rating: IP65 (standard wiper design)
- Max thrust: 7850N @0.7MPa (extending)
High-load industrial cylinder engineered for heavy-duty linear motion applications. Features precision honed tube with wear-resistant coating and dual anti-rotation guide rods (optional). Requires 40μm filtered lubricated air (ISO 8573-1 class 4). Includes magnetic piston for position sensing compatibility.
- Automotive press line material handling systems
- Steel coil stacking/unstacking machinery
- Plastic injection molding ejector mechanisms
- Shipbuilding plate bending equipment
- Wind turbine component assembly lines
Installation guidelines:
Maximum side load ≤15% of dynamic thrust. For vertical mounting,
use mechanical locks. Lubricate through air supply (ISO VG32).
Allow 50mm clearance behind rod end for maintenance.
| Property | Property Value |
|---|---|
| sku | JSI100X1400S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | <1400mm> |
