Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X100-40
2. Features profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3. JSI series adopts aluminum tube with internal cross rib reinforcement (rodless design), offering enhanced corrosion resistance;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5. Smooth cushioning adjustment mechanism for stable operation;
6. Available in multiple configurations with comprehensive cylinder mounting accessories.
Category: Standard Cylinders | Brand: AIRTAC | Series: JSIJ100~125
AirTAC JSIJ100X100-40 Adjustable Cylinder Technical Details
- Series: JSIJ100~125 Adjustable Stroke Series
- Bore Size: 100mm (3.94")
- Stroke: 100mm ±1mm adjustable (3.94")
- Operating Pressure: 0.05~0.9 MPa (7~130 PSI)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning: Adjustable elastic cushion + air cushion
- Port Size: G3/8 (NPT1/4 optional)
- Mounting: Basic type (MF1) with front flange
- Rod End: Female thread M20×1.5
- Piston Material: Aluminum alloy with hard anodizing
- Seal Type: NBR + PU combination seals
- Repeat Positioning Accuracy: ±0.5mm
- Weight: 3.8kg (8.38 lbs)
- Dimensions: 280mm(L) × 100mm(W) × 100mm(H)
- ISO Standard: 6432 (Mounting dimensions compatible)
- Protection Class: IP54 (Standard), IP67 optional
High-precision adjustable stroke cylinder featuring dual cushioning system and micro-stroke adjustment mechanism (40mm adjustment range). The hardened piston rod with multi-layered sealing ensures 2,000km+ service life under standard conditions. Includes magnetic piston for sensor compatibility.
- Variable height positioning in automated assembly lines
- Pressure-sensitive clamping devices
- Packaging machine stroke adjustment systems
- Plastic injection molding ejectors
- Precision alignment in CNC tool changers
Operation Tip:
For optimal performance, maintain lubrication with ISO VG32 hydraulic oil mist (1 drop/3 cycles).
Avoid side load exceeding 30N. Adjustment screw requires 2.5mm hex key - turn clockwise to shorten stroke (max 40mm reduction).
| Property | Property Value |
|---|---|
| sku | JSIJ100X100-40 |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 100mm |
