Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X100-40S
2. Features profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3. JSI series adopts aluminum tube with internal cross rib reinforcement (rodless design), offering enhanced corrosion resistance;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5. Smooth cushioning adjustment mechanism for stable operation;
6. Available in multiple configurations with comprehensive cylinder mounting accessories.
Category: Standard Cylinders | Brand: AIRTAC | Series: JSIJ100~125
AirTAC JSIJ100X100-40S Adjustable Stroke Cylinder Specifications
- Series: JSIJ100~125 (Standard Adjustable Stroke)
- Model: JSIJ100X100-40S
- Bore size: Ø100mm
- Stroke length: 100mm (manually adjustable)
- Operating pressure: 0.05~1.0 MPa
- Temperature range: -10℃ to 70℃
- Cushioning: Adjustable air cushion (both ends)
- Mounting type: Basic type (Standard foot & front flange)
- Port size: G1/2 (Rc1/2 optional)
- Piston speed: 50~750 mm/s
- Rod thread: M24×1.5
- Material: Aluminum alloy body, CRMo steel piston rod
- Seal type: NBR + PU combination
- Weight: 6.8 kg (±2%)
- Dimensions (L×W×H): 370mm × 140mm × 140mm (extended length)
- Protection rating: IP54 (standard), IP67 (optional)
Heavy-duty adjustable stroke cylinder with dual-side position sensing slots, designed for precision stroke control in industrial automation. Features corrosion-resistant anodized surface and multi-layer sealing system. Includes built-in shock absorption and adjustable stroke locking mechanism with ±0.5mm repeatability.
- Die casting machine ejection systems
- Automotive assembly line positioning
- Press tool height adjustment mechanisms
- Material handling equipment stops
- Plastic injection molding gates control
Installation note:
Requires minimum 1.5x bore size clearance for stroke adjustment.
Lubricate piston rod weekly with ISO VG32 hydraulic oil.
Use locknut (included) to secure stroke setting under vibration conditions.
| Property | Property Value |
|---|---|
| sku | JSIJ100X100-40S |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 100mm |
