Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X100-50
2. Features profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3. JSI series adopts aluminum tube with internal cross rib reinforcement (rodless design), offering enhanced corrosion resistance;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5. Smooth cushioning adjustment mechanism for stable operation;
6. Available in multiple configurations with comprehensive cylinder mounting accessories.
Category: Standard Cylinders | Brand: AIRTAC | Series: JSIJ100~125
AirTAC JSIJ100~125 Adjustable Cylinder (JSIJ100X100-50) Specifications
- Model Code: JSIJ100X100-50
- Series: JSIJ100~125 adjustable stroke cylinder
- Bore Size: 100mm
- Stroke: 100mm (±50mm adjustable range)
- Operating Pressure: 0.05–0.8 MPa
- Temperature Range: -20℃ to 80℃
- Cushion Type: Adjustable rubber buffer
- Mounting Style: Basic type (MF1 standard)
- Port Size: G3/8 (NPT1/4 optional)
- Piston Speed: 50–700 mm/s
- Tube Material: Aluminum alloy (hard anodized)
- Rod Material: Chrome-plated carbon steel
- Seal Material: NBR (nitrile rubber)
- Weight: 5.2kg (with standard accessories)
- Dimensions: 302mm(L) × 125mm(W) × 125mm(H)
- Protection Class: IP54 (standard wiper design)
Precision stroke-adjustable cylinder with mechanical lock mechanism, featuring ±50mm stroke adjustment through external screw control. The dual-chamber buffer system minimizes end-impact noise. Corrosion-resistant construction with integrated mounting grooves allows direct sensor installation.
- Variable position clamping in CNC fixtures
- Packaging line product height adjustment
- Press machine force control systems
- Automated woodworking equipment
- Plastic injection mold core pulling
Installation note:
Engage lock nut after stroke adjustment. Lubricate with ISO VG32 hydraulic oil.
Avoid lateral force exceeding 30N during operation. Regular lubrication interval:
3 months or 500km stroke distance.
| Property | Property Value |
|---|---|
| sku | JSIJ100X100-50 |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 100mm |
