Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X100-75
$189.12
Regular price
$196.62
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
JSIJ100X100-75
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. JIS Standard Triple Cylinder;
2. Features profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3. JSI series adopts aluminum tube with internal cross rib reinforcement (rodless design), offering enhanced corrosion resistance;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5. Smooth cushioning adjustment mechanism for stable operation;
6. Available in multiple configurations with comprehensive cylinder mounting accessories.
Category: Standard Cylinders | Brand: AIRTAC | Series: JSIJ100~125
Operational guidance:
For optimal performance, maintain 0.3-1.0 MPa lubrication pressure using ISO VG32 hydraulic oil.
Avoid side load exceeding 15% of maximum thrust capacity. Perform stroke calibration every 50,000 cycles.
Critical note:
Always engage mechanical lock before manual stroke adjustment.
Do not exceed 80% of maximum stroke during high-speed (>500mm/s) operations.
2. Features profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3. JSI series adopts aluminum tube with internal cross rib reinforcement (rodless design), offering enhanced corrosion resistance;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5. Smooth cushioning adjustment mechanism for stable operation;
6. Available in multiple configurations with comprehensive cylinder mounting accessories.
Category: Standard Cylinders | Brand: AIRTAC | Series: JSIJ100~125
AirTAC JSIJ100~125 Adjustable Stroke Cylinder (JSIJ100X100-75) Technical Details
- Series: JSIJ Adjustable Stroke Cylinder Series
- Full model: JSIJ100X100-75
- Bore size range: Φ100mm - Φ125mm (series coverage)
- Stroke: 100mm (adjustable within 0-100% range)
- Stroke adjustment mechanism: External screw-type stroke limiter
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Rubber buffer + adjustable air cushion
- Mounting style: Basic foot mounting (MF1 type)
- Port size: G3/8 (NPT1/2 optional)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated carbon steel
- Seal type: NBR seals (PU optional)
- Weight: 3.8kg (without accessories)
- Dimensions:
- Body length: 275mm (minimum retracted length)
- Stroke extension: +100mm (maximum extended length)
- Width: 118mm (mounting base width)
- Height: 128mm (including rod end)
Precision adjustable stroke cylinder featuring dual-position locking mechanism and wear-resistant construction. The JSIJ series combines 5μm precision honed tube with integrated cushioning adjustment, enabling micron-level positioning repeatability. Includes anti-rotation rod design for stable load handling.
Industrial Applications:
- Variable height work platforms in automotive assembly
- Pressure-sensitive material handling systems
- Plastic injection molding ejector mechanisms
- Semiconductor wafer processing equipment
- Precision stamping press feed adjustments
Operational guidance:
For optimal performance, maintain 0.3-1.0 MPa lubrication pressure using ISO VG32 hydraulic oil.
Avoid side load exceeding 15% of maximum thrust capacity. Perform stroke calibration every 50,000 cycles.
Critical note:
Always engage mechanical lock before manual stroke adjustment.
Do not exceed 80% of maximum stroke during high-speed (>500mm/s) operations.
| Property | Property Value |
|---|---|
| sku | JSIJ100X100-75 |
| Adjustable Stroke | 75mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 100mm |
