Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X100-75S
2. Features profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3. JSI series adopts aluminum tube with internal cross rib reinforcement (rodless design), offering enhanced corrosion resistance;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5. Smooth cushioning adjustment mechanism for stable operation;
6. Available in multiple configurations with comprehensive cylinder mounting accessories.
Category: Standard Cylinders | Brand: AIRTAC | Series: JSIJ100~125
AirTAC JSIJ100~125 Adjustable Cylinder (JSIJ100X100-75S) Specifications
- Series: JSIJ100~125 Stroke Adjustable Cylinder
- Full model: JSIJ100X100-75S
- Bore size: 100mm (4")
- Stroke: 100mm (adjustable range: 25-100mm)
- Rod end type: Female thread (M20×1.5)
- Operating pressure: 0.05-1.0 MPa
- Ambient temperature: -10℃ to 70℃
- Cushioning: Adjustable rubber bumper
- Mounting: Basic type (no foot)
- Rod material: Carbon steel with hard chrome plating
- Tube material: Aluminum alloy (anodized)
- Seal type: NBR + PU combination
- Weight: 3.8kg ±5%
- Dimensions:
- Extended length: 325mm
- Retracted length: 225mm
- Body diameter: Φ125mm
- Mounting hole spacing: 115×115mm
Heavy-duty adjustable stroke cylinder with precision positioning capability. Features dual-side stroke adjustment screws (locknut protected) for millimeter-level positioning accuracy. The 75S suffix indicates special sealing for high-humidity environments. Includes built-in magnet for position sensing compatibility.
- Die casting machine ejection systems
- Automotive welding fixture positioning
- Plastic injection molding clamp adjustment
- Paper converting equipment tension control
- Glass manufacturing conveyor stops
Operation tip:
Always lubricate through air port (ISO VG32 recommended) before initial use.
For stroke adjustment: Loosen locknut, turn adjustment screw (1 full rotation ≈ 1.5mm stroke change),
then retighten with 4.5-5.5N·m torque.
| Property | Property Value |
|---|---|
| sku | JSIJ100X100-75S |
| Adjustable Stroke | 75mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 100mm |
