Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-100S
2. Features profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3. JSI series adopts aluminum tube with internal cross rib reinforcement (rodless design), offering enhanced corrosion resistance;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5. Smooth cushioning adjustment mechanism for stable operation;
6. Available in multiple configurations with comprehensive cylinder mounting accessories.
Category: Standard Cylinders | Brand: AIRTAC | Series: JSIJ100~125
AirTAC JSIJ100~125 Adjustable Stroke Cylinder (JSIJ100X1000-100S) Specifications
- Series: JSIJ Adjustable Stroke Cylinder Series
- Bore size range: 100-125mm (This model: 100mm)
- Stroke: 1000mm (Max adjustable stroke)
- Adjustment range: 0-100mm (Mechanical stopper system)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -10℃ to 70℃
- Cushioning type: Adjustable air cushion (both ends)
- Port size: G1/2 (NPT1/2 optional)
- Piston rod thread: M20×1.5 (Standard)
- Mounting type: Basic type (MF1) with front flange
- Material:
- Tube: Aluminum alloy hard anodized
- Piston rod: Chrome-plated steel
- End caps: Die-cast aluminum
- Weight: ~5.8kg (Excluding mounting accessories)
- Dimensions:
- Extended length: ~1230mm (Stroke 1000mm)
- Body diameter: Ø125mm
- Mounting flange width: 150mm
- Rod end thread length: 30mm
Heavy-duty adjustable stroke cylinder with precision mechanical stopper system, featuring dual-side cushion adjustment for smooth deceleration. The corrosion-resistant construction and oversized rod bearing design ensure extended service life in high lateral load applications. Requires 5μm filtered lubricated air (ISO 8573-1 class 3.4.3).
- Automated assembly line positioning systems
- Die casting machine ejection control
- Automotive welding fixture positioning
- Packaging machine pressure adjustment mechanisms
- Press tooling with variable height requirements
Installation note:
Ensure proper alignment of mechanical stopper adjustment bolts and lubricate guide shafts monthly.
Maximum side load capacity: 350N at mid-stroke. Allow 50mm clearance for stopper adjustment.
| Property | Property Value |
|---|---|
| sku | JSIJ100X1000-100S |
| Adjustable Stroke | 100mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
