Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-20S
2. Features profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3. JSI series adopts aluminum tube with internal cross rib reinforcement (rodless design), offering enhanced corrosion resistance;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5. Smooth cushioning adjustment mechanism for stable operation;
6. Available in multiple configurations with comprehensive cylinder mounting accessories.
Category: Standard Cylinders | Brand: AIRTAC | Series: JSIJ100~125
AirTAC JSIJ100~125 Adjustable Cylinder JSIJ100X1000-20S Technical Details
- Full model: JSIJ100X1000-20S
- Series: JSIJ (Precision Adjustable Stroke Series)
- Bore size: 100mm (Available in 100/125mm variants)
- Stroke: 1000mm (Customizable stroke adjustment)
- Operating pressure: 0.1-0.9 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Mounting style: MF1 front flange with rear trunnion (20S code)
- Temperature range: -20℃ to 80℃
- Port size: G3/8 (Standard) / Optional NPT1/2
- Rod end thread: M20×1.5 (ISO metric standard)
- Material: Aluminum alloy barrel, Chrome-plated piston rod
- Seal type: NBR wear-resistant seals
- Weight: 12.7kg ±3% (Without accessories)
- Dimensions: 1135mm(L) × 150mm(W) × 150mm(H)
- Repeat accuracy: ±0.5mm
- Max theoretical thrust: 706N @0.63MPa
- Lubrication: Pre-lubricated (Oil-free operation possible)
High-precision adjustable stroke cylinder featuring dual-side position sensing slots and micro-stroke adjustment capability (±5mm fine-tuning). The 20S mounting configuration provides enhanced stability for long-stroke applications. Corrosion-resistant design with IP54 protection rating ensures reliable performance in humid environments. Includes built-in magnetic piston for proximity sensor compatibility.
- Automated production line positioning systems
- Die-casting machine ejection mechanisms
- Paper converting equipment with variable web lengths
- Glass manufacturing conveyor adjustments
- Packaging machine tray height customization
Installation tip:
For optimal performance in vertical mounting positions,
use model-specific guide brackets (ASQZ-100 accessory recommended).
Maintain 0.5-1mm alignment tolerance during installation.
| Property | Property Value |
|---|---|
| sku | JSIJ100X1000-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
