Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-30S
2. Features profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3. JSI series adopts aluminum tube with internal cross rib reinforcement (rodless design), offering enhanced corrosion resistance;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5. Smooth cushioning adjustment mechanism for stable operation;
6. Available in multiple configurations with comprehensive cylinder mounting accessories.
Category: Standard Cylinders | Brand: AIRTAC | Series: JSIJ100~125
AirTAC JSIJ100X1000-30S Adjustable Cylinder Specifications
- Series: JSIJ100~125 Adjustable Stroke Series
- Model Code: JSIJ100X1000-30S
- Bore Size: 100mm (3.94")
- Stroke: 1000mm (39.37") adjustable
- Operating Pressure: 0.05~1.0 MPa
- Piston Speed: 50~800 mm/s
- Ambient Temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffers at both ends
- Port Size: G3/8 (NPT1/2 optional)
- Mounting Type: Standard ISO 15552 foot & front flange (30S code)
- Rod End: Male thread M20×1.5
- Material: Aluminum alloy barrel, hardened chromium piston rod
- Seal Type: NBR seals with wear-resistant ring
- Weight: 12.8 kg (28.2 lbs) ±3%
- Dimensions (L×W×H): 1280mm×120mm×120mm (50.4"×4.7"×4.7")
- Repeat Positioning Accuracy: ±0.5mm
- ISO Certification: 6431/15552 compliant
Heavy-duty adjustable stroke cylinder with precision stroke adjustment mechanism (external locking nut system). Features dual-cushion impact absorption and IP65-rated dust/water protection. Optional magnetic piston version (add "-M" suffix) for sensor integration. Requires 40μm filtered air with ISO VG32 lubricator oil.
- Automated palletizing systems requiring variable stroke
- Plastic injection molding machine ejectors
- Automotive assembly line positioning arms
- Paper processing equipment with adjustable compression
- Solar panel production line handling systems
Installation note:
Maintain 0.5mm minimum clearance between rod and guide mechanisms.
For vertical mounting, use auxiliary rod support brackets (sold separately).
Lubricate piston rod weekly in high-cycle applications (>500 cycles/day).
| Property | Property Value |
|---|---|
| sku | JSIJ100X1000-30S |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
