Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-40S
2. Features profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3. JSI series adopts aluminum tube with internal cross rib reinforcement (rodless design), offering enhanced corrosion resistance;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5. Smooth cushioning adjustment mechanism for stable operation;
6. Available in multiple configurations with comprehensive cylinder mounting accessories.
Category: Standard Cylinders | Brand: AIRTAC | Series: JSIJ100~125
AirTAC JSIJ100~125 Adjustable Stroke Cylinder (JSIJ100X1000-40S) Specifications
- Series: JSIJ Adjustable Stroke Cylinder Series
- Bore size: 100mm (JSIJ100)
- Stroke: 1000mm (adjustable via external stopper)
- Operating pressure: 0.1–0.9 MPa
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable air cushion at both ends
- Mounting type: 40S - Front flange with square base (ISO 15552 standard)
- Rod end: Male thread M24×1.5
- Material: Aluminum alloy barrel, chromium-plated piston rod
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 14.8 kg (excluding accessories)
- Dimensions:
- Barrel outer diameter: 125mm
- Retracted length: 1165mm (1000mm stroke + 165mm end caps)
- Extended length: 2165mm
- Mounting flange: 200mm×200mm square base
- Mounting hole pattern: 160mm×160mm (4×M12 threaded holes)
High-precision adjustable stroke cylinder with dual cushioning control, designed for applications requiring variable positioning in long-stroke operations. Features wear-resistant chromium plating on piston rod and integrated magnet for position sensing compatibility. Optional shock absorber kits available for high-speed applications.
- Automated production line material handling
- Packaging machine pusher mechanisms
- Automotive assembly positioning fixtures
- Plastic injection molding ejection systems
- Lumber processing equipment
Installation notes:
- Ensure proper alignment of guide rails for full stroke movement
- Use 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 quality
- Apply lithium soap-based grease (Molykote 33M) every 500km of operation
- Maximum side load: 350N at full extension
| Property | Property Value |
|---|---|
| sku | JSIJ100X1000-40S |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
