Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-50S
2. Features profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3. JSI series adopts aluminum tube with internal cross rib reinforcement (rodless design), offering enhanced corrosion resistance;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5. Smooth cushioning adjustment mechanism for stable operation;
6. Available in multiple configurations with comprehensive cylinder mounting accessories.
Category: Standard Cylinders | Brand: AIRTAC | Series: JSIJ100~125
AirTAC JSIJ100X1000-50S Adjustable Cylinder Specifications
- Series: JSIJ100~125 Adjustable Stroke Cylinder
- Model: JSIJ100X1000-50S
- Bore size: Ø100 mm
- Stroke: 1000 mm (adjustable)
- Operating pressure: 0.05~1.0 MPa
- Action type: Double acting
- Cushioning: Adjustable pneumatic cushion (both ends)
- Temperature range: -20℃ to 80℃
- Port size: G1/2
- Piston material: High-strength aluminum alloy (hard anodized)
- Rod material: Chrome-plated steel (Cr-Mo steel base)
- Seal type: NBR+PU combination seals
- Mounting type: Basic type (no built-in mounting)
- Weight: 28.5 kg ±2% (without accessories)
- Dimensions:
- Extended length: 1420 mm
- Retracted length: 420 mm
- Body diameter: 118 mm
- Rod end thread: M50×1.5
- Adjustment mechanism: External stroke adjustment locknut
- Position detection: Optional magnetic switch groove (ISO 21287 compatible)
Heavy-duty adjustable stroke cylinder with precision stroke locking capability, featuring dual anti-rotation design for stable long-stroke operation. The chrome-plated piston rod incorporates a multi-layer sealing system for dust resistance (IP65 equivalent). Requires 40μm filtered lubricated air (ISO 8573-1 class 4).
- Die casting machine ejection systems
- Automotive assembly line positioning devices
- Steel coil handling equipment
- Large-format CNC press brake tooling
- Plastic injection molding machine core pulls
Installation note:
Requires minimum 0.3 mm/m alignment tolerance during mounting. Stroke adjustment must be performed at mid-pressure (0.3-0.5 MPa). For full stroke applications, reduce operating speed below 500 mm/s to prevent cushion damage.
| Property | Property Value |
|---|---|
| sku | JSIJ100X1000-50S |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
