Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-75S
2. Features profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3. JSI series adopts aluminum tube with internal cross rib reinforcement (rodless design), offering enhanced corrosion resistance;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5. Smooth cushioning adjustment mechanism for stable operation;
6. Available in multiple configurations with comprehensive cylinder mounting accessories.
Category: Standard Cylinders | Brand: AIRTAC | Series: JSIJ100~125
AirTAC JSIJ100X1000-75S Adjustable Cylinder Specifications
- Model: JSIJ100X1000-75S
- Series: JSIJ100~125 adjustable stroke series
- Bore size: 100mm
- Stroke: 1000mm (adjustable)
- Operating pressure: 0.1~0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable elastic cushion
- Mounting type: MS75S front flange with integrated mounting slots
- Port size: G3/8 (NPT1/2 optional)
- Rod material: Chrome-plated carbon steel
- Tube material: Aluminum alloy with hard anodization
- Seals: NBR (Nitrile) standard, optional Polyurethane
- Weight: 8.7kg (excluding accessories)
- Dimensions:
- Extended length: 1255mm
- Retracted length: 255mm
- Body diameter: 100mm
- Mounting flange width: 75mm
Heavy-duty adjustable stroke cylinder with precision positioning capability, featuring dual-axis end lock mechanism for stable stroke adjustment. The hardened piston rod and wear-resistant guide rings ensure smooth operation in high-cycle applications. Includes magnetic piston for position sensing compatibility.
- Automated production line positioning systems
- Material handling equipment stroke control
- Automotive welding fixture positioning
- Packaging machine product height adjustment
- Die casting machine ejection mechanisms
Installation note:
Requires minimum 0.5mm/m alignment tolerance during mounting.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Stroke adjustment should be performed at mid-pressure (0.3-0.5MPa).
| Property | Property Value |
|---|---|
| sku | JSIJ100X1000-75S |
| Adjustable Stroke | 75mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
