Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X125-10
2. Features profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3. JSI series adopts aluminum tube with internal cross rib reinforcement (rodless design), offering enhanced corrosion resistance;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5. Smooth cushioning adjustment mechanism for stable operation;
6. Available in multiple configurations with comprehensive cylinder mounting accessories.
Category: Standard Cylinders | Brand: AIRTAC | Series: JSIJ100~125
AirTAC JSIJ100X125-10 Adjustable Cylinder Specifications
- Model Series: JSIJ100~125
- Specific Model: JSIJ100X125-10
- Type: Double-acting adjustable stroke cylinder
- Bore Size: 100mm (3.94")
- Stroke: 125mm (4.92")
- Working Pressure: 0.05-1.0 MPa (7-145 PSI)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting: Standard ISO 15552 foot & front flange
- Operating Temperature: -20℃ to 80℃ (-4°F to 176°F)
- Piston Material: Anodized aluminum alloy
- Rod Material: Hard chrome-plated steel
- Seal Type: NBR+PU combination seals
- Port Size: G1/2 (BSPP thread)
- Weight: 3.8kg (8.38 lbs)
- Dimensions (L×W×H):
- Extended Length: 334mm (13.15")
- Retracted Length: 209mm (8.23")
- Body Diameter: φ100mm (3.94")
- Mounting Base: 125×125mm (4.92"×4.92")
Precision-engineered adjustable stroke cylinder featuring dual micro-adjustment screws (±5mm stroke adjustment) for fine position tuning. The through-rod design allows external stroke indication, while the multi-layer sealing system ensures ≤0.5mm/s creep speed under load. Includes magnetic piston for sensor compatibility and anti-rotation guide mechanism.
- Automated production line positioning fixtures
- Die-casting machine ejection systems
- Palletizing robot end-effectors
- Plastic injection molding clamping units
- Precision press brake tooling adjustment
Installation note:
Maintain ≤0.1mm/m alignment tolerance during mounting. Lubricate with ISO VG32 turbine oil
during initial setup. For stroke adjustment: loosen locknut, turn adjustment screw (1 full rotation = 2mm stroke change),
then retighten to 4.5N·m torque.
| Property | Property Value |
|---|---|
| sku | JSIJ100X125-10 |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 125mm |
