Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X125-100
2. Features profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3. JSI series adopts aluminum tube with internal cross rib reinforcement (rodless design), offering enhanced corrosion resistance;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5. Smooth cushioning adjustment mechanism for stable operation;
6. Available in multiple configurations with comprehensive cylinder mounting accessories.
Category: Standard Cylinders | Brand: AIRTAC | Series: JSIJ100~125
AirTAC JSIJ100X125-100 Adjustable Cylinder Specifications
- Model: JSIJ100X125-100
- Series: JSIJ (Adjustable Stroke Type)
- Bore Size: 100mm (Standard) - 125mm (Extended)
- Stroke Adjustment Range: 50-125mm (Mechanically Adjustable)
- Max. Effective Stroke: 100mm (Optimized for Precision)
- Operating Pressure: 0.15–1.0 MPa
- Piston Speed: 50-750 mm/s
- Cushioning: Adjustable Air Cushion (Both Ends)
- Port Size: G1/2 (ISO Standard)
- Ambient Temperature: -20℃ to 80℃
- Seal Material: NBR + PU Hybrid Seals
- Body Material: Anodized Aluminum Alloy (A6063)
- Rod Material: Chrome-Plated Steel (STS420J2)
- Weight: 5.8kg (Without Accessories)
- Dimensions: 325mm(L) × 112mm(W) × 112mm(H) (Mid-Stroke Position)
- Mounting: Standard ISO 15552 Foot & Flange Options
- Repeat Positioning Accuracy: ±0.5mm
High-precision adjustable stroke cylinder with dual-position locking mechanism, featuring a unique stroke adjustment collar with visual scale (1mm graduations). The chrome-plated piston rod integrates wear-resistant coating technology, suitable for high-cycle applications. Requires 5μm filtered lubricated air (ISO 8573-1 Class 3).
- Variable-height positioning in automotive welding jigs
- Press-fit force control for electronic component assembly
- Adjustable clamping force in CNC fixture systems
- Packaging line product height compensation mechanisms
- Glass handling equipment with variable thickness adaptation
Operation Tip:
For optimal performance, lock adjustment collar at 25Nm torque using included hex key.
Lubricate guide shafts monthly with ISO VG32 hydraulic oil. Avoid full extension during storage.
Critical Note:
Maximum side load capacity 180N. For vertical installations exceeding 45° angle,
always use rod-end support brackets (sold separately).
| Property | Property Value |
|---|---|
| sku | JSIJ100X125-100 |
| Adjustable Stroke | 100mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 125mm |
