Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-10S
2、Features specially-shaped bidirectional sealing structure with integrated oil reservoir for compact piston sealing design;
3、JSI series adopts tie-rod-free construction with H-shaped aluminum tube for enhanced corrosion resistance;
4、Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5、Precision-engineered cushioning adjustment ensures smooth stroke termination;
6、Comprehensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Standard Cylinders , Brand: AIRTAC , Series: JSIJ32~50
AirTAC JSIJ32X100-10S Adjustable Cylinder Specifications
- Series: JSIJ32~50 Adjustable Stroke Series
- Model: JSIJ32X100-10S
- Bore size: 32mm
- Stroke: 100mm (±5° adjustable)
- Mounting type: Standard foot mounting (MF1)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: G1/8 (ISO standard)
- Cushioning: Adjustable elastic cushion
- Material: Aluminum alloy body, NBR seals
- Weight: 1.2kg (without accessories)
- Dimensions: 170mm(L) × 45mm(W) × 52mm(H)
- Rod end type: Female thread M10×1.25
- Max thrust: 230N at 0.6MPa
- Protection class: IP54 (standard)
Precision adjustable stroke cylinder with ±5° stroke angle correction capability, featuring dual-position locking mechanism for stable positioning. The anodized aluminum construction ensures corrosion resistance in humid environments. Integrated shock absorption reduces end-impact noise to below 75dB.
- Conveyor line positioning systems
- Plastic injection molding ejectors
- Automated welding fixture adjustment
- Textile machinery tension control
- Semiconductor handling equipment
Installation notes:
- Align piston rod within 0.5mm lateral tolerance during mounting
- Apply ISO VG32 hydraulic oil for initial lubrication
- Maintain 0.3mm minimum clearance from adjacent components
- Limit side load to ≤15% of maximum thrust capacity
| Property | Property Value |
|---|---|
| sku | JSIJ32X100-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | <20mm> |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
