Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-20S
2、Features specially-shaped bidirectional sealing structure with integrated oil reservoir for compact piston sealing design;
3、JSI series adopts tie-rod-free construction with H-shaped aluminum tube for enhanced corrosion resistance;
4、Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5、Precision-engineered cushioning adjustment ensures smooth stroke termination;
6、Comprehensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Standard Cylinders , Brand: AIRTAC , Series: JSIJ32~50
AirTAC JSIJ32X100-20S Adjustable Cylinder Specifications
- Model Series: JSIJ32~50 (32mm/40mm/50mm bore sizes)
- Full Model: JSIJ32X100-20S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 32mm (±0.5mm tolerance)
- Stroke: 100mm (adjustable within 95-105mm range)
- Operating pressure: 0.1~0.9 MPa
- Cushioning: Adjustable elastic cushion at both ends
- Port size: G1/8 (M5×0.8 optional)
- Mounting type: Basic fixed type (MF1)
- Temperature range: -20℃ to 80℃
- Body material: Aluminum alloy (A6063-T5)
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 1.45kg (with standard accessories)
- Dimensions:
- Extended length: 229mm
- Retracted length: 129mm
- Body width: 52mm
- Mounting height: 32mm
Precision-adjustable pneumatic cylinder featuring mechanical stroke adjustment mechanism with ±5mm fine-tuning capability. The hexagonal rod design prevents rotation during operation, while built-in magnet (S version) enables position sensing. Corrosion-resistant construction with IP54 protection rating ensures reliability in humid environments.
- Precision stop positioning in conveyor systems
- Die-cutting machine pressure adjustment
- Electronic component insertion mechanisms
- Glass handling equipment with variable grip distances
- Automated test fixture positioning
Installation note:
Use locknuts (included) for stroke adjustment - clockwise rotation decreases stroke by 1.5mm per full turn.
Maintain 0.5mm minimum air gap between rod end and workpiece. Lubricate with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | JSIJ32X100-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | <20mm> |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
