Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-30S
2、Features specially-shaped bidirectional sealing structure with integrated oil reservoir for compact piston sealing design;
3、JSI series adopts tie-rod-free construction with H-shaped aluminum tube for enhanced corrosion resistance;
4、Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5、Precision-engineered cushioning adjustment ensures smooth stroke termination;
6、Comprehensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Standard Cylinders , Brand: AIRTAC , Series: JSIJ32~50
AirTAC JSIJ32X100-30S Adjustable Cylinder Specifications
- Series: JSIJ32~50 Adjustable Stroke Series
- Bore size: 32mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.15–1.0 MPa
- Cushion type: Adjustable air cushion (both ends)
- Piston speed: 50–1000mm/s
- Ambient temperature: -20℃ to 80℃
- Lubrication: Required (ISO VG32 or equivalent)
- Mounting type: Basic type (AXW style)
- Port size: M5×0.8 (Rc1/8 optional)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated carbon steel
- Seal material: NBR (nitrile rubber)
- Weight: 1.8kg ±5%
- Dimensions (L×W×H): 206mm × 50mm × 50mm (retracted length)
- Stroke tolerance: ±2.0mm
- Repeat positioning accuracy: ±0.5mm
Precision adjustable stroke cylinder featuring dual-position locking mechanism with graduated scale for visual stroke confirmation. The enhanced cushion design reduces end-impact noise by 40% compared to standard models. Integrated magnet slots enable sensor mounting for position feedback. Corrosion-resistant construction with IP54 rating ensures reliable operation in dusty environments.
- Packaging line product positioning gates
- CNC machine tool clamping mechanisms
- Automated assembly station stoppers
- Printing press paper feed adjustments
- Glass cutting equipment pressure control
Installation note:
Always lock adjustment screws with 1.2-1.5N·m torque after stroke setting.
Maintain 0.3-0.5mm clearance between rod end and load during alignment.
| Property | Property Value |
|---|---|
| sku | JSIJ32X100-30S |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | <20mm> |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
