Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-50S
2、Features specially-shaped bidirectional sealing structure with integrated oil reservoir for compact piston sealing design;
3、JSI series adopts tie-rod-free construction with H-shaped aluminum tube for enhanced corrosion resistance;
4、Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5、Precision-engineered cushioning adjustment ensures smooth stroke termination;
6、Comprehensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Standard Cylinders , Brand: AIRTAC , Series: JSIJ32~50
AirTAC JSIJ32X100-50S Adjustable Cylinder Specifications
- Series: JSIJ32~50 Adjustable Stroke Cylinder
- Model: JSIJ32X100-50S
- Bore size: 32mm (Standard series)
- Stroke: 100mm (Adjustable through built-in stroke adjustment mechanism)
- Operating pressure: 0.05–0.8 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy body with hard anodized surface
- Seal material: NBR (Nitrile rubber) standard
- Port size: G1/8 (ISO standard thread)
- Mounting type: Basic type (no built-in mounting features)
- Rod end type: Female thread M10×1.25
- Weight: 1.8kg ±5% (including mounting accessories)
- Dimensions:
- Extended length: 200mm (stroke 100mm + retracted length)
- Body diameter: 50mm (maximum outer dimension)
- Mounting base width: 80mm
- Rod diameter: 12mm
Precision-adjustable pneumatic cylinder featuring a unique dual-lock stroke adjustment system with ±2mm positioning accuracy. The 50S variant includes enhanced dust resistance with integrated wiper seals, making it suitable for particulate-heavy environments. Requires 5μm filtered air and ISO VG32-grade lubricant.
- Precision positioning in semiconductor handling robots
- Variable clamping force applications in CNC fixture systems
- Packaging line product height adjustment mechanisms
- Automated door stroke limitation in cleanroom environments
- Textile machinery tension control systems
Installation guidelines:
Always engage both adjustment lock nuts after stroke setting.
Maintain 0.5-1mm alignment tolerance during mounting.
Lubricate every 500km of cumulative travel or 6 months.
| Property | Property Value |
|---|---|
| sku | JSIJ32X100-50S |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | <20mm> |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
