Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X120-30S
2、Features specially-shaped bidirectional sealing structure with integrated oil reservoir for compact piston sealing design;
3、JSI series adopts tie-rod-free construction with H-shaped aluminum tube for enhanced corrosion resistance;
4、Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5、Precision-engineered cushioning adjustment ensures smooth stroke termination;
6、Comprehensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Standard Cylinders , Brand: AIRTAC , Series: JSIJ32~50
AirTAC JSIJ32X120-30S Adjustable Cylinder Specifications
- Model Series: JSIJ32~50 (Size range: 32mm/40mm/50mm bore)
- Full Model: JSIJ32X120-30S
- Bore Size: 32mm
- Stroke: 120mm (adjustable with stopper mechanism)
- Operating Pressure: 0.05-0.9 MPa
- Port Size: M5x0.8 (1/8" NPT optional)
- Cushioning: Fixed cushion + adjustable external stopper
- Mounting Type: 30S (Standard foot mounting with front flange)
- Temperature Range: -20℃ to 80℃
- Piston Material: Aluminum alloy with hard anodizing
- Rod Material: Chrome-plated steel
- Seal Type: NBR seals (HNBR available for high-temp versions)
- Weight: 1.85kg ±2% (with accessories)
- Dimensions:
- Extended Length: 282mm
- Retracted Length: 162mm
- Body Diameter: 42mm
- Mounting Base: 85mm × 32mm
- Accessories: Includes adjustable stopper locknuts (2pcs), cushion valves (2pcs)
High-precision adjustable stroke cylinder featuring dual-position locking mechanism for millimeter-level positioning accuracy. The external stopper allows ±3mm fine-tuning without disassembly. Corrosion-resistant design with IP54 protection rating makes it suitable for harsh environments. Requires minimal lubrication (1-2 drops of ISO VG32 oil per 1 million cycles).
- Precision workpiece clamping in CNC fixtures
- Variable height positioning in conveyor systems
- Packaging machine product ejection control
- Semiconductor handling equipment
- 3D printer bed adjustment mechanisms
Installation tip:
When adjusting stroke length, always loosen both locknuts simultaneously
and retighten to 1.2-1.5N·m torque. Use thread-locking compound on stopper
screws for high-vibration applications.
| Property | Property Value |
|---|---|
| sku | JSIJ32X120-30S |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | <20mm> |
| Bore Diameter | <32 mm> |
| Stroke | 120mm |
