Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X125-10
2、Features specially-shaped bidirectional sealing structure with integrated oil reservoir for compact piston sealing design;
3、JSI series adopts tie-rod-free construction with H-shaped aluminum tube for enhanced corrosion resistance;
4、Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5、Precision-engineered cushioning adjustment ensures smooth stroke termination;
6、Comprehensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Standard Cylinders , Brand: AIRTAC , Series: JSIJ32~50
AirTAC JSIJ32X125-10 Adjustable Cylinder Technical Details
- Series: JSIJ32~50 (Adjustable Stroke Series)
- Bore size: 32mm
- Stroke: 125mm (Adjustable range: 0-125mm)
- Operating pressure: 0.05~0.8 MPa
- Cushioning type: Adjustable rubber buffer (both ends)
- Mounting style: Front flange (Standard), optional rear flange/bracket
- Rod end thread: M12×1.25 (External)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (SUS304 equivalent)
- Seal type: NBR + PU combination seals
- Temperature range: -20℃ to 80℃
- Port size: G1/8 (ISO standard)
- Weight: 1.85kg ±3% (Without accessories)
- Dimensions: 250mm(L) × 52mm(W) × 52mm(H) (Max extended length)
- Repeat positioning accuracy: ±0.5mm
- Lubrication: Pre-lubricated (Oil-free operation possible)
Precision-adjustable pneumatic cylinder featuring dual-axis stroke adjustment screws with locknuts for stable positioning. The hexagonal barrel design enables tool-free stroke setting through 120° rotation of end caps. Includes wear-resistant guide bushings and anti-rotation mechanism for vertical load applications.
- Variable height work platforms in assembly lines
- Clamping force adjustment in CNC fixture systems
- Material handling with position-sensitive grippers
- Printing machinery paper feed mechanisms
- Packaging machine product height compensation
Installation protocol:
Align cylinder axis within 0.2mm perpendicularity tolerance.
For vertical mounting, use M12 locknut with 15-20N·m torque.
Adjust cushioning after stroke setting - turn clockwise to increase damping.
| Property | Property Value |
|---|---|
| sku | JSIJ32X125-10 |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Cushion Stroke | <20mm> |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
