Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X125-100
2、Features specially-shaped bidirectional sealing structure with integrated oil reservoir for compact piston sealing design;
3、JSI series adopts tie-rod-free construction with H-shaped aluminum tube for enhanced corrosion resistance;
4、Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5、Precision-engineered cushioning adjustment ensures smooth stroke termination;
6、Comprehensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Standard Cylinders , Brand: AIRTAC , Series: JSIJ32~50
AirTAC JSIJ32X125-100 Adjustable Cylinder Technical Details
- Series: JSIJ32~50 (Adjustable Stroke Series)
- Bore size: 32mm (Standard series includes 32/40/50mm options)
- Stroke: 125mm (Adjustable through built-in stroke limiter)
- Mounting type: Front flange + Rear foot (MF1/F1 standard)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃ (Dry air required below 0℃)
- Cushioning: Adjustable pneumatic cushion (Dual-side)
- Port size: G1/8 (NPT1/4 optional)
- Rod material: Chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR + Polyurethane combination
- Weight: 1.85 kg (Without accessories)
- Dimensions:
- Length: 228mm (Min. retracted length)
- Width: 48mm (Mounting flange width)
- Height: 62mm (Including rod end)
- Rod thread: M12×1.25 (Female thread)
- Lubrication: Pre-lubricated (Oil mist lubrication recommended)
Precision adjustable stroke cylinder with dual-position locking mechanism, featuring 360° adjustable cushion needle valves for smooth motion control. The anodized barrel provides corrosion resistance in humid environments. Includes magnetic piston for position sensing compatibility (Sensor not included). Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.3 purity.
- Variable position clamping in CNC fixtures
- Packaging line product ejection systems
- Automated door stroke adjustment mechanisms
- Textile machinery tension control units
- Semiconductor handling equipment positioners
Installation protocol:
Maximum side load ≤15% of thrust rating. For vertical mounting,
use counterbalance valves. Stroke adjustment requires 17mm hex wrench
(included). Lubricate every 3 months under normal operation.
| Property | Property Value |
|---|---|
| sku | JSIJ32X125-100 |
| Adjustable Stroke | 100mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Cushion Stroke | <20mm> |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
