Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X125-20
2、Features specially-shaped bidirectional sealing structure with integrated oil reservoir for compact piston sealing design;
3、JSI series adopts tie-rod-free construction with H-shaped aluminum tube for enhanced corrosion resistance;
4、Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5、Precision-engineered cushioning adjustment ensures smooth stroke termination;
6、Comprehensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Standard Cylinders , Brand: AIRTAC , Series: JSIJ32~50
AirTAC JSIJ32X125-20 Adjustable Cylinder Specifications
- Series: JSIJ32~50 Adjustable Stroke Series
- Model: JSIJ32X125-20
- Bore size: Ø32mm
- Stroke: 125mm (adjustable range: 0-125mm)
- Operating pressure: 0.15–0.85 MPa
- Piston speed: 50–800 mm/s
- Cushioning type: Adjustable elastic cushion (both ends)
- Mounting style: Basic MF1 (ISO 15552 standard)
- Port size: M5x0.8 (Rc1/8/NPT1/8 optional)
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Weight: 1.45kg ±3%
- Dimensions: 200mm(L) × 50mm(W) × 50mm(H) (retracted position)
- Rod thread: M10x1.25 (external)
- Mounting hole spacing: 40mm (vertical) × 25mm (horizontal)
Precision-adjustable pneumatic cylinder featuring dual-position locking mechanism with hex socket adjustment screws. The micrometer-style stroke adjustment allows ±0.5mm positioning accuracy. Integrated magnet for position sensing compatibility (sensor not included). Features wear-resistant guide bushings and IP54 protection rating.
- Precision clamping fixtures in CNC machining centers
- Variable height positioning in automated assembly lines
- Packaging machine stopper adjustment systems
- Textile machinery tension control mechanisms
- Semiconductor handling equipment
Installation notes:
- Use locknut (included) to secure adjustment screws after positioning
- Lubricate with ISO VG32 turbine oil before initial operation
- Maintain 15mm clearance around adjustment mechanism for maintenance
- For vertical mounting, install air vent filter on upper port
| Property | Property Value |
|---|---|
| sku | JSIJ32X125-20 |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Cushion Stroke | <20mm> |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
