Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X125-30
2、Features specially-shaped bidirectional sealing structure with integrated oil reservoir for compact piston sealing design;
3、JSI series adopts tie-rod-free construction with H-shaped aluminum tube for enhanced corrosion resistance;
4、Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5、Precision-engineered cushioning adjustment ensures smooth stroke termination;
6、Comprehensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Standard Cylinders , Brand: AIRTAC , Series: JSIJ32~50
AirTAC JSIJ32X125-30 Adjustable Stroke Cylinder Specifications
- Series: JSIJ32~50 (Compact ISO Cylinder with Adjustable Stroke)
- Bore size: 32mm
- Stroke: 125mm (adjustable through mechanical stopper)
- Adjustment code: -30 (indicates 30mm maximum stroke reduction)
- Operating pressure: 0.05–1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning: Rubber bumper + adjustable air cushion
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Piston material: Aluminum alloy with hard anodized surface
- Rod material: Chrome-plated steel
- Seal type: NBR (Nitrile) seals standard, FKM available for high temp
- Mounting: Basic type (no built-in mounts) with optional accessories
- Weight: 1.25kg ±3% (without accessories)
- Dimensions:
- Length: 211mm (min. retracted length)
- Width: 54mm (max. body width)
- Height: 59mm (including rod end)
- Durability: 5,000km stroke life at 0.5MPa (ISO 15552 standard)
Precision-adjustable pneumatic cylinder featuring dual-position mechanical stroke adjustment via rotary stopper mechanism. The chrome-plated piston rod integrates wiper seal for contamination resistance. Includes auto-switch mounting slots for sensor integration. Requires 40μm filtered air with lubrication (ISO VG32 recommended).
- Packaging machine stopper positioning
- CNC fixture clamping with variable workpiece sizes
- Electronics assembly pick-and-place units
- Textile machinery tension control systems
- Pharmaceutical dosing equipment
Adjustment procedure:
Loosen lock nut → Rotate stopper collar (1 full rotation = 2mm stroke change) →
Retighten at desired position. Always perform test strokes after adjustment.
| Property | Property Value |
|---|---|
| sku | JSIJ32X125-30 |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Cushion Stroke | <20mm> |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
