Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X125-40S
2、Features specially-shaped bidirectional sealing structure with integrated oil reservoir for compact piston sealing design;
3、JSI series adopts tie-rod-free construction with H-shaped aluminum tube for enhanced corrosion resistance;
4、Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5、Precision-engineered cushioning adjustment ensures smooth stroke termination;
6、Comprehensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Standard Cylinders , Brand: AIRTAC , Series: JSIJ32~50
AirTAC JSIJ32X125-40S Adjustable Stroke Cylinder Specifications
- Series: JSIJ32~50 Adjustable Stroke Cylinder
- Full model: JSIJ32X125-40S
- Bore size: 32mm (1-1/4")
- Stroke: 125mm (adjustable within 0-125mm range)
- Operation type: Double-acting
- Working pressure: 0.15–0.8 MPa (21.7–116 psi)
- Piston speed: 50–1000mm/s
- Cushioning: Adjustable elastic cushion (both ends)
- Port size: M5x0.8 (Rc1/8/NPT1/8 optional)
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Body material: Aluminum alloy (anodized)
- Rod material: Chrome-plated carbon steel
- Weight: 1.4kg (3.08 lbs)
- Dimensions:
- Total length: 236mm (at max extension)
- Body diameter: 50mm
- Mounting base: 40mm x 40mm
- Rod diameter: 12mm
- ISO standard: 6432
- Protection rating: IP54
Precision adjustable stroke cylinder featuring micro-positioning capability (±0.5mm repeat accuracy) through integrated stroke adjustment screws. The dual-cushion design minimizes end-impact vibration, while the hard-anodized barrel provides exceptional wear resistance. Includes anti-rotation guide for stable linear motion.
- Precision clamping fixtures in CNC machining centers
- Variable height positioning in automated assembly lines
- Pressure-sensitive material handling systems
- Packaging machine product ejection mechanisms
- Semiconductor wafer handling equipment
Installation guidelines:
Maintain 0.5mm minimum clearance between adjustment screws and stoppers during setup.
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side-load exceeding 30N.
| Property | Property Value |
|---|---|
| sku | JSIJ32X125-40S |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | <20mm> |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
