Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X125-50
2、Features specially-shaped bidirectional sealing structure with integrated oil reservoir for compact piston sealing design;
3、JSI series adopts tie-rod-free construction with H-shaped aluminum tube for enhanced corrosion resistance;
4、Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5、Precision-engineered cushioning adjustment ensures smooth stroke termination;
6、Comprehensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Standard Cylinders , Brand: AIRTAC , Series: JSIJ32~50
AirTAC JSIJ32X125-50 Adjustable Cylinder Specifications
- Model Series: JSIJ32~50 (Adjustable Stroke)
- Specific Model: JSIJ32X125-50
- Bore Size: 32mm (Standard Series)
- Stroke: 125mm (Adjustable via mechanical stopper)
- Operating Pressure: 0.05~0.9 MPa
- Cushioning: Adjustable rubber bumper (both ends)
- Mounting Style: Basic Type (MF1) with axial mounting holes
- Port Size: M5x0.8 (Standard) / Optional NPT1/8
- Piston Speed: 50~750 mm/s
- Ambient Temperature: -10℃ to 70℃ (NBR seals)
- Material: Aluminum alloy barrel, CRCA piston rod
- Rod End Thread: M10x1.25 (Male)
- Weight: 2.3kg ±5% (Without accessories)
- Dimensions: 200mm(L) × 50mm(W) × 50mm(H) (Cylinder body only)
- Stroke Tolerance: ±1.5mm
- Repeat Accuracy: ±0.5mm
Compact adjustable stroke cylinder with dual-side position locking mechanism. Features corrosion-resistant anodized surface and integrated auto-lubrication design. The stroke adjustment uses a hex wrench-operated stopper system (included) for millimeter-level precision. Requires 40μm filtered air and monthly lubrication for optimal performance.
- Precision clamping fixtures in CNC machines
- Variable height positioning in packaging lines
- Material handling with adjustable gripping depth
- Semiconductor wafer transfer systems
- Automated door stroke adjustment mechanisms
Installation tip:
Lock adjustment screws with 0.8-1.2N·m torque after setting stroke.
Maintain 15mm clearance behind cylinder for stopper access. Avoid side-load exceeding 30N.
| Property | Property Value |
|---|---|
| sku | JSIJ32X125-50 |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Cushion Stroke | <20mm> |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
