Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X125-75
2、Features specially-shaped bidirectional sealing structure with integrated oil reservoir for compact piston sealing design;
3、JSI series adopts tie-rod-free construction with H-shaped aluminum tube for enhanced corrosion resistance;
4、Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5、Precision-engineered cushioning adjustment ensures smooth stroke termination;
6、Comprehensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Standard Cylinders , Brand: AIRTAC , Series: JSIJ32~50
AirTAC JSIJ32X125-75 Adjustable Stroke Cylinder Technical Details
- Full model designation: JSIJ32X125-75
- Bore size: 32mm (JSIJ series range: 32-50mm)
- Maximum stroke: 125mm
- Adjustment range: 50-75mm (±25mm from center)
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning type: Elastic buffer + external stopper
- Mounting style: Basic type (MF1 standard)
- Port size: G1/8 (NPT1/8 optional)
- Rod end: Male thread M10×1.25
- Material: Aluminum alloy body, NBR seals
- Weight: 1.45kg (bare cylinder), 1.68kg with accessories
- Dimensions: 200mm(L) × 82mm(W) × 82mm(H) (retracted position)
- Repeat positioning accuracy: ±0.5mm
- Max theoretical thrust: 226N @0.5MPa
Mechanically adjustable stroke cylinder with dual-position locking mechanism, featuring a unique T-slot design for tool-free stroke adjustment. The chrome-plated piston rod integrates wear-resistant scrapers, optimized for frequent mid-stroke operations. Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
- Precision workpiece clamping in CNC machining centers
- Variable height positioning in conveyor sorting systems
- Mold height adjustment in injection molding machines
- Tool changer positioning in robotic arms
- Batch-specific adjustment in pharmaceutical packaging lines
Installation guidance:
Mount with 0.05mm maximum misalignment tolerance. For vertical installations,
use anti-rotation brackets (sold separately). Adjust stroke while depressurizing
system - turn adjustment bolts clockwise to reduce stroke length.
| Property | Property Value |
|---|---|
| sku | JSIJ32X125-75 |
| Adjustable Stroke | 75mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Cushion Stroke | <20mm> |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
