Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X125-75S
2、Features specially-shaped bidirectional sealing structure with integrated oil reservoir for compact piston sealing design;
3、JSI series adopts tie-rod-free construction with H-shaped aluminum tube for enhanced corrosion resistance;
4、Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5、Precision-engineered cushioning adjustment ensures smooth stroke termination;
6、Comprehensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Standard Cylinders , Brand: AIRTAC , Series: JSIJ32~50
AirTAC JSIJ32X125-75S Adjustable Cylinder Specifications
- Series: JSIJ32~50 Adjustable Stroke Series
- Model: JSIJ32X125-75S
- Bore size: 32mm
- Stroke: Adjustable 25-125mm (initial preset 75mm)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Rubber buffer + adjustable cushion screw
- Mounting type: Basic type (MF1) with front/rear flange
- Port size: M5x0.8 (G1/8 equivalent)
- Rod end: Female thread M10x1.25
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (non-rotating design)
- Seal type: NBR seals with wear-resistant ring
- Ambient temperature: -10℃ to 80℃
- Weight: 1.65kg ±2%
- Dimensions (L×W×H):
- Retracted length: 202mm
- Extended length: 327mm (at max stroke)
- Body width: 52mm
- Mounting flange height: 18mm
- Protection class: IP54 (standard)
- Lubrication: Pre-lubricated (DOP mist compatible)
Precision adjustable stroke cylinder featuring dual-position locking mechanism for stroke adjustment. The unique 360° rotatable cushion screw allows fine-tuning of end position damping. Anti-rotation rod design ensures precise linear motion, with chrome-plated rod resistant to side loads up to 15% of maximum thrust.
- Variable position clamping fixtures
- Packaging machine stopper adjustment systems
- Automated assembly with position-sensitive tooling
- Printing press roller engagement mechanisms
- Material handling with variable lift heights
Operation tip:
Always unlock the stroke adjustment lock nut before rotating the cushion screw.
Maximum adjustment should not exceed 150% of initial preset stroke.
Recommend using with 40μm filtered air and weekly lubrication for high-cycle applications.
| Property | Property Value |
|---|---|
| sku | JSIJ32X125-75S |
| Adjustable Stroke | 75mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | <20mm> |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
