Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X135-10S
2、Features specially-shaped bidirectional sealing structure with integrated oil reservoir for compact piston sealing design;
3、JSI series adopts tie-rod-free construction with H-shaped aluminum tube for enhanced corrosion resistance;
4、Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5、Precision-engineered cushioning adjustment ensures smooth stroke termination;
6、Comprehensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Standard Cylinders , Brand: AIRTAC , Series: JSIJ32~50
AirTAC JSIJ32~50 Adjustable Stroke Cylinder JSIJ32X135-10S Technical Details
- Full Model: JSIJ32X135-10S
- Series: JSIJ (Compact adjustable stroke cylinder)
- Bore size range: 32-50mm (This model: Ø32mm)
- Stroke: 135mm (adjustable via mechanical stopper)
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: G1/8 (M5 available on request)
- Cushioning: Rubber buffer + adjustable cushion screw
- Stroke adjustment range: 0-135mm (continuous positioning)
- Body material: Aluminum alloy (A6063-T5)
- Rod material: Hard chrome-plated steel (S45C)
- Seal material: NBR (Nitrile rubber)
- Weight: 1.65kg (without accessories)
- Dimensions:
- Total length (retracted): 235mm
- Total length (extended): 235mm + stroke
- Body diameter: 52mm
- Mounting base: 32×32mm square pattern
- ISO standard: 6432 (compact cylinder specifications)
- Lubrication: Pre-lubricated (Oil-free operation possible)
Precision adjustable stroke cylinder featuring a unique dual-lock positioning mechanism with ±0.5mm repeatability. The 10S suffix indicates stainless steel mounting brackets and enhanced dust resistance. Includes integrated shock absorbers and maintenance-free guides. Requires 5μm filtered air with ISO 8573-1:2010 [4:4:3] class.
- CNC machine tool clamping systems
- Pharmaceutical blister packaging positioning
- Electronics PCB press-fit mechanisms
- Automotive window regulator testing jigs
- Food processing portion control devices
Installation protocol:
Use M6 mounting screws with 12mm engagement depth. Align within 0.2mm perpendicularity tolerance.
For vertical installations, add 20% safety factor to load calculations. Lubricate guide shafts monthly with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | JSIJ32X135-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | <20mm> |
| Bore Diameter | <32 mm> |
| Stroke | 135mm |
