Airtac MALJ20 Adjustable Mini Cylinder MALJ20X55-10-S
2、Front/rear end caps feature threaded connection design;
3、Piston sealing adopts specialized bidirectional sealing structure with compact dimensions and integrated oil reservoir function;
4、Front end incorporates self-lubricating bearing guides for enhanced lubrication and directional stability;
5、Multiple rear mounting configurations enable flexible cylinder installation;
6、Available with various cylinder sizes and compatible mounting accessories for customized configurations.
Category: Adjustable Cylinders | Brand: Airtac | Series: MALJ20
AirTAC MALJ20X55-10-S Adjustable Miniature Cylinder Specifications
- Model: MALJ20X55-10-S
- Type: Single-acting spring return cylinder
- Bore size: 20mm
- Stroke: 55mm (adjustable ±3mm)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable rubber buffer
- Mounting style: Front flange (MF1)
- Port size: M5×0.8 (dual ports)
- Operating temperature: -20℃ to 80℃
- Seal material: NBR (nitrile rubber)
- Piston rod material: Stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- Weight: 0.42kg ±2%
- Dimensions: 150mm(L) × 34mm(W) × 34mm(H)
Ultra-compact cylinder with precision stroke adjustment, featuring a built-in locknut for position retention after calibration. The dual-port design allows flexible pneumatic circuit integration. Corrosion-resistant construction with IP54-rated dust/water protection. Requires ISO 8573-1:2010 Class 3 lubricated air (32μm filtration).
- PCB handling robots in electronics manufacturing
- Precision clamping in optical lens production
- Valve actuation in medical analyzers
- Sorting mechanisms in pharmaceutical packaging
- Miniature assembly jigs for watchmaking
Installation note:
Use torque-controlled tightening (1.2-1.5N·m) for mounting screws.
Lubricate rod weekly with ISO VG32 hydraulic oil. Avoid side-load
forces exceeding 15N to prevent rod deflection.
| Property | Property Value |
|---|---|
| sku | MALJ20X55-10-S |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 55mm |
