Airtac MALJ25 Adjustable Mini Air Cylinder MALJ25X30-10
2. Front/rear end covers feature threaded connections for secure assembly and maintenance;
3. Specially designed bi-directional piston seal structure with compact design and integrated oil reservoir functionality;
4. Front end incorporates self-lubricating bearings for smooth guiding and low friction operation;
5. Multiple rear mounting configurations (base, pivot, flange) for flexible installation solutions;
6. Comprehensive range of cylinder accessories and mounting brackets available for customized pneumatic system integration.
Category: Adjustable Cylinders , Brand: Airtac , Series: MALJ25
AirTAC MALJ25X30-10 Adjustable Mini Cylinder Specifications
- Model: MALJ25X30-10
- Series: MALJ (Mini Adjustable Cushion)
- Bore size: 25mm
- Stroke: 30mm ±0.5mm
- Operation type: Double-acting
- Working pressure: 0.1–0.9 MPa
- Ambient temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Piston speed: 50–1000 mm/s
- Port size: M5×0.8 (Rc1/8/NPT1/8 optional)
- Material: Aluminum alloy barrel, SUS304 piston rod
- Seal material: NBR (Nitrile Butadiene Rubber)
- Weight: 0.25 kg
- Dimensions: 100mm(L) × 60mm(W) × 60mm(H) (fully retracted)
- Mounting type: Basic type (no built-in mounting brackets)
- ISO standard: 6432
Ultra-compact pneumatic cylinder featuring adjustable cushioning for precise end-position control. The MALJ25 series combines reduced installation space (30% smaller than standard cylinders) with enhanced position stability (±0.5mm repeatability). Anti-rotation design maintains orientation during operation. Compatible with guided cylinder configurations.
- PCB handling robots in electronics manufacturing
- Precision clamping fixtures for CNC machining
- Medical device actuation systems
- Automated packaging line pusher mechanisms
- Laboratory sample positioning stages
Installation guidance:
For optimal performance, maintain 0.3-0.5mm alignment tolerance during mounting.
Lubricate with ISO VG32 hydraulic oil if operating below -10℃. Avoid side load exceeding 5N.
| Property | Property Value |
|---|---|
| sku | MALJ25X30-10 |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 30mm |
