Airtac MALJ25 Adjustable Mini Air Cylinder MALJ25X75-30-S
2. Front/rear end covers feature threaded connections for secure assembly and maintenance;
3. Specially designed bi-directional piston seal structure with compact design and integrated oil reservoir functionality;
4. Front end incorporates self-lubricating bearings for smooth guiding and low friction operation;
5. Multiple rear mounting configurations (base, pivot, flange) for flexible installation solutions;
6. Comprehensive range of cylinder accessories and mounting brackets available for customized pneumatic system integration.
Category: Adjustable Cylinders , Brand: Airtac , Series: MALJ25
AirTAC MALJ25X75-30-S Adjustable Miniature Cylinder Specifications
- Model: MALJ25X75-30-S
- Type: Double-acting with adjustable cushioning
- Bore size: 25mm
- Stroke: 75mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Mounting style: Foot-mounted with adjustable stopper
- Cushioning type: External adjustable pneumatic cushion
- Port thread: M5×0.8 (standard) / NPT1/8 optional
- Piston rod thread: M6×1 external thread
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (nitrile rubber)
- Weight: 420g ±5% (without accessories)
- Dimensions:
- Total length: 132mm (at mid-stroke position)
- Width: 45mm (mounting foot span)
- Height: 50mm (including rod end)
- Stroke adjustment range: ±3mm via locking nut
- Max theoretical force:
- Thrust @0.6MPa: 294N (66.1 lbf)
- Tension @0.6MPa: 257N (57.8 lbf)
Ultra-compact linear actuator featuring precision stroke adjustment via dual locking nuts. The gold-anodized barrel provides enhanced corrosion resistance, while the chrome-plated piston rod ensures smooth operation. Includes built-in magnetic sensor slot (G1/8") for position feedback. Requires 40μm filtered air with ISO VG32 lubrication recommended for high-cycle applications.
- PCB handling robots in electronics manufacturing
- Precision dosing mechanisms in pharmaceutical packaging
- Optical lens positioning systems
- Semiconductor wafer processing equipment
- High-speed sorting gates in logistics automation
Installation tip:
For optimal performance, align cylinder axis within 0.2mm perpendicularity tolerance.
Adjust cushion screws gradually (1/4 turn increments) while monitoring impact velocity.
Use anti-vibration washers when mounting to aluminum extrusions.
| Property | Property Value |
|---|---|
| sku | MALJ25X75-30-S |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 75mm |
