Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X10-10S
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
AirTAC MBLCJ Adjustable Miniature Cylinder MBLCJ20X10-10S Specifications
- Model: MBLCJ20X10-10S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 10mm (adjustable ±1mm via built-in stopper)
- Operating pressure: 0.05–0.9 MPa
- Medium temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: M5x0.8 (Rc1/8/NPT1/8 optional)
- Rod thread: M6x1.0 male thread
- Mounting type: 10mm side-mount grooves (ISO 15552 compatible)
- Piston material: Aluminum alloy with hard anodizing
- Seal material: NBR (Nitrile rubber)
- Weight: 235g ±5g (excluding accessories)
- Dimensions:
- Extended length: 103mm
- Retracted length: 93mm
- Body width: 32mm
- Height with rod: 44mm
- ISO standard: Compliant with ISO 6432 (VDMA 24562)
Ultra-compact cylinder featuring dual-position stroke adjustment through integrated mechanical stoppers. The anodized aluminum construction provides corrosion resistance for humid environments. Includes wear-resistant guide bands for smooth operation up to 3 m/s piston speed. Requires 5μm filtered air (ISO 8573-1 class 4) and lubrication-free operation.
- PCB handling robots in electronics manufacturing
- Precision clamping in optical lens production
- Valve actuation in laboratory analyzers
- Medical device positioning mechanisms
- Packaging machine ejector systems
Installation note:
For optimal performance, maintain 0.5-1mm clearance between adjustable stopper and cylinder head during stroke setting. Lubricate guide shafts with ISO VG32 hydraulic oil if used below -10℃.
| Property | Property Value |
|---|---|
| sku | MBLCJ20X10-10S |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
