Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X100-100
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
AirTAC MBLCJ Adjustable Miniature Cylinder MBLCJ20X100-100 Specifications
- Model: MBLCJ20X100-100
- Bore size: 20mm
- Stroke: 100mm (adjustable)
- Adjustment range: ±2mm (mechanical screw type)
- Operating pressure: 0.05-0.9 MPa
- Port size: M5x0.8 (standard), optional NPT1/8
- Cushioning: Rubber buffer + adjustable damping
- Piston speed: 50-750 mm/s
- Ambient temperature: -20℃ to 80℃
- Mounting type: Basic type (no foot)
- Rod end: Female thread M6x1.0
- Body material: Aluminum alloy (hard anodized)
- Seal material: NBR/PU
- Weight: 380g ±5%
- Dimensions:
- Length (retracted): 143mm
- Length (extended): 243mm
- Width: 34mm
- Height: 34mm
Ultra-compact linear actuator with precision stroke adjustment capability, featuring dual cushioning system for smooth end-of-stroke deceleration. The hard anodized surface treatment provides enhanced corrosion resistance in humid environments. Integrated magnetic sensor slots (non-inductive model) allow for position detection integration.
- PCB handling robots in electronics assembly
- Precision clamping devices for CNC tool changers
- Pharmaceutical tablet counting/packaging machines
- Semiconductor wafer processing equipment
- Automated coffee machine brew mechanisms
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load exceeding 2N·m.
For vertical mounting, use locking nut (accessory code: ANM6) to secure adjustment screw.
- Magnetic sensors: D-A93 (3-wire NPN/PNP)
- Mounting brackets: MFH12/MFH16 series
- Speed controllers: ASC2000-02 (needle valve)
| Property | Property Value |
|---|---|
| sku | MBLCJ20X100-100 |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
