Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X100-40S
$43.49
Regular price
$50.99
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MBLCJ20X100-40S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Complies with AIRTAC enterprise standards, featuring an aluminum round tube barrel construction;
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
Operational guidance:
For optimal performance, maintain air supply dew point below 3℃.
Adjust cushion screws in 1/4 turn increments during commissioning.
Lubricate with ISO VG32 hydraulic oil if operating below 0.5Hz cycle rate.
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
AirTAC MBLCJ Adjustable Mini Cylinder MBLCJ20X100-40S Technical Details
- Model Code: MBLCJ20X100-40S
- Type: Compact adjustable stroke double-acting cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (ISO 6149 thread)
- Buffer type: External adjustable rubber cushion (both ends)
- Mounting style: 4xM4 threaded holes (base mounting)
- Rod material: Chrome-plated steel (3-5μm coating)
- Cylinder tube: Aluminum alloy (hard anodized surface)
- Seal type: NBR + PU combination seals
- Repeat positioning accuracy: ±0.2mm
- Weight: ~0.85kg (with standard fittings)
- Dimensions (L×W×H):
- Extended length: 195mm
- Retracted length: 95mm
- Body width: 40mm
- Height with bracket: 54mm
Ultra-compact linear actuator featuring micrometer-grade stroke adjustment capability through dual external buffer screws. The hard-anodized body provides corrosion resistance in humid environments. Includes built-in magnetic sensor slots (non-inductive model) for position feedback integration.
Industrial Applications:
- Precision clamping in SMT component placement machines
- Valve actuation in portable medical analyzers
- Cartesian robot Z-axis positioning
- Semiconductor wafer handling systems
- Food packaging portion control mechanisms
Operational guidance:
For optimal performance, maintain air supply dew point below 3℃.
Adjust cushion screws in 1/4 turn increments during commissioning.
Lubricate with ISO VG32 hydraulic oil if operating below 0.5Hz cycle rate.
⚠️ Critical Notice:
Maximum side load capacity 15N.
Avoid continuous operation above 80% duty cycle when using full stroke.
Requires 5μm filtration for compressed air supply.
| Property | Property Value |
|---|---|
| sku | MBLCJ20X100-40S |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
