Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X125-30S
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
AirTAC MBLCJ Adjustable Miniature Cylinder MBLCJ20X125-30S Technical Details
- Model Code: MBLCJ20X125-30S
- Bore Size: 20mm (ISO 6432 standard)
- Stroke: 125mm (±0.5mm tolerance)
- Operation Type: Double-acting
- Adjustable Cushion: 30° rotary adjustable (both ends)
- Operating Pressure: 0.05-1.0 MPa
- Ambient Temperature: -20℃ to 80℃
- Piston Speed: 50-750 mm/s (optimal at 200 mm/s)
- Mounting Type: Basic type with axial mounting holes
- Port Size: M5x0.8 (Rc1/8/NPT1/8 optional)
- Seal Material: NBR (Nitrile) with wear-resistant ring
- Body Material: Anodized aluminum alloy (hard coat)
- Rod Material: Stainless steel SUS304
- Weight: 0.85kg (excluding accessories)
- Dimensions:
- Total Length (L): 195mm (stroke + 70mm base)
- Width (W): 34mm (mounting block)
- Height (H): 40mm (including rod end)
- Protection Class: IP40 (standard), IP67 optional
- Lubrication: Pre-lubricated (DOP mist compatible)
Ultra-compact linear actuator featuring precision-machined components and 360° adjustable stroke end cushions. The dual-piston design ensures smooth operation with ≤0.15mm axial play. Includes magnetic piston for sensor compatibility (PNP/NPN switch ready). Requires 40μm filtered air with max 1mg/m³ oil content.
- PCB handling robots in electronics manufacturing
- Dispenser valve actuation in food packaging lines
- Micro-positioning in optical lens assembly
- Medical device automation (IVD equipment)
- Semiconductor wafer transfer mechanisms
Installation guidelines:
Apply 2-3Nm torque for mounting screws. For vertical installations,
use rod-down orientation to prevent piston drift. Perform 50-cycle
break-in at 0.3MPa before full operation.
| Property | Property Value |
|---|---|
| sku | MBLCJ20X125-30S |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
